10 DR
®
POWERWAGON-PRO
Oil Fil
Fuel Fil
Figure 2
Adding Oil and Gasoline
YOU MUST ADD OIL BEFORE STARTING THE ENGINE. THIS MACHINE SHIPPED WITHOUT OIL.
TRACES OF OIL MAY BE IN THE RESERVOIR FROM FACTORY TESTING, BUT YOU MUST ADD OIL
BEFORE STARTING THE ENGINE. FILL THE RESERVOIR SLOWLY, CHECKING THE DIPSTICK
FREQUENTLY TO AVOID OVERFILLING.
Engine Oil Capacity
Briggs & Stratton 6.75 Torque, Quantum
20 oz. (0.60 L)
Tip: To avoid confusion, we recommend leaving
the Caps on the Fuel and Oil Fills until you
are ready to pour either gasoline or oil into
the correct Fill.
Use only SAE 30 High Detergent oil. Other types
of oil could cause problems operating your
machine. Please refer to your Engine Owner’s
Manual for detailed oil information.
NOTE: You must remove the tool tray to access
the Oil and Fuel Reservoirs.
1. Place the machine on a level surface and initially add
16 oz. (1/2 quart) of SAE 30 High Detergent oil
recommended by the Engine Manufacturer and wait
one minute for the oil to settle (Figure 2).
2. Check the Dipstick and continue adding a few ounces
of oil at a time, rechecking the Dipstick until the oil
reaches the fill mark. Be careful not to overfill.
3. Fill the Fuel Tank to not more than 1/4" from the
bottom of the Fill Neck with fresh, unleaded gas. See
the Engine Manufacturer’s Owner’s Manual for more
information.
TO GET AN ACCURATE READING WHEN CHECKING THE OIL LEVEL:
• THE MACHINE SHOULD BE ON A LEVEL SURFACE.
• THE DIPSTICK SHOULD BE SCREWED DOWN ON BRIGGS & STRATTON ENGINES.
Tool Tray
