Contact us at www.DRpower.com 37
Parts List - Main Axle Assembly
NOTE: Part numbers listed are available through DR Power Equipment. Not all parts appear on all diagrams.
Ref# Part# Description
03 108921 Flange, Ball Bearing, 2-Hole
04 152171 Bearing, Ball, 3/4" Bore
12 151181 Bracket, Brake Cable, Orange
14 187631 Cable, Brake, 73-1/2"
36 112161 Wheel, 16 x 6.50-8, Turf
37 193121 Wheel, Gray, 16 x 6.50-8, Terrain
49 106381 Key, Square, 3/16" x 1-1/2"
50 160521 Shim, 3/4" ID, 1.0" OD, 1/4" L
52 112371 Washer, Flat, 10-24, USS
53 112381 Washer, Flat, 1/4", USS
58 106401 Key, woodruff, 3/16" x 3/4"
73 110691 Nut, 5/16-18, ZP
80 110761 Nut, Nylon Lock, 5/16"-18
91 111501 Screw, 1/4"-28 x 3/4"
101 123361 Bolt, 5/16"-18 x 1-1/4", HCS
102 111591 Bolt, 5/16"-18 x 2-1/2", HCS
117 160351 Tie Rod, 39.09" Rod & Ball Ends
132 111721 Screw, 5/16"-18 x 3/4", Tri-Lobe
139 108891 Hanger, Transaxle, Front
140 108791 Arm, Shift, Transaxle
141 178931 Transaxle, 4 Fwd, 1 Rev
144 111141 Pulley, 7.0", V-Belt, 5/8" Bore
150 111261 Ring, Retaining, 3/4", Type E
157 123211 Bolt, 5/16"-18 x 3/4", HCS
191 129691 Shim, .75" ID, 1.125" OD, .06" L, ZP
