Contact us at www.DRpower.com 35
CHAPTER 7: PARTS LISTS, SCHEMATIC DIAGRAMS AND WARRANTY
Parts List - Main Frame Assembly
NOTE: Part numbers listed are available through DR Power Equipment. Not all parts appear on all diagrams.
Ref# Part# Description
01 253871 Engine, 6.75 TQ, B&S, E/S
253861 Engine, 6.75 TQ, B&S, M/S
05 104831 Battery, 17AH, 12V
06 124511 Clamp, Battery, 7-1/8"W x 5.5"H
07 193151 Wire, 6.0", Battery, Positive
08 193161 Wire, 6.5", Battery, Negative
16 109341 Bumper, Stop
17 164121 Bumper, Strip, 2-1/2"
30 109621 Collar, 1/2" ID
46 108731 Stop Angle, Flat Bed
49 106381 Key, Square, 3/16" x 1-1/2"
53 112381 Washer, Flat, 1/4", USS
54 164301 Frame, Main
61 214181 Handle, Latch, w/Roll Pin
62 110241 Grip, Latch Handle
63 110451 Housing, Latch
64 111931 Spring, C, .545" OD x .055" Wire
66 111291 Lower Shift Rod, w/Arm
70 110701 Nut, 1/4"-20
78 110731 Nut, Nylon Lock, 1/4"-20
79 110751 Nut, Nylon Lock, 3/8"-16
80 110761 Nut, Nylon Lock, 5/16"-18
86 114701 Bolt, 1/4"-20 x 1/2", HCS
87 111531 Bolt, 3/8"-16 x 2-1/4", HCS
90 111441 Bolt, 1/2"-13 x 2", HCS
92 160861 Bolt, 1/4"-20 x 1-1/4", HCS
93 111481 Bolt, 1/4"-20 x 1-3/4", HCS
94 111461 Bolt, 1/4"-20 x 2-1/2", HCS
95 111491 Bolt, 1/4"-20 x 1", HCS
96 165131 Bolt, 3/8"-24 x 1-1/4", HCS, Gr8
99 134431 Bolt, 5/16"-18 x 1-1/2", HCS
100 150451 Bolt, 5/16"-18 x 1-3/4", HCS
101 123361 Bolt, 5/16"-18 x 1-1/4", HCS
110 180991 Screw, 10-24 x 1", Phillips
114 160871 Coupling, Shift Lever
Ref# Part# Description
117 160351 Tie Rod, 39.09" Rod & Ball Ends
128 112501 Washer, Lock, 5/16"
131 112581 Wheel, Caster, 4.10/3.50-4
136 136601 Leg, Tray Frame
142 136621 Arm, Idler
143 113071 Pulley, Flat, Idler, 2-1/4"
146 111161 Pulley, 4.0", V-Belt, Idler
148 108971 Belt, A82, 1/2" x 84"
149 126971 Washer, Fender, 1/4" ID x 1" OD
152 111991 Strap, Weight Rack Block
154 160821 Tray, Weight
157 180811 Washer, Split Lock, 3/8"
158 165141 Washer, .385" ID, 1.39" OD
159 189221 Spacer, .877" ID, 1.125" OD, .75" L
160 165021 Spring, E, .500" OD x .067" Wire
164 112121 Throttle w/Cable, 43"
169 109491 Cap, 3/4" Round Tubing
171 221111 Clutch, Centrifugal, w/Pulley
185 160831 Guard, Belt Cover, Rear
186 160841 Guard, Belt Cover, Front
196 147281 O-Ring, Swivel Wheel
Safety Labels
124371 Label, American Flag
127811 Label, Warning, Add Oil
137581 Label, Check Oil
153421 Label, Dump Lever
153431 Label, Dump Lever latch
153441 Label, 20 degree Slope limit
153451 Label, Throttle Control
153601 Label, ID & Serial Number
192021 Label, DR Logo, 4" circle
113011 Charger, Battery
125021 Parts Bag
Not Illustrated
112531 Weight Block, 4" x 8" x 16"
