Removing and Replacing the Front Wheels

WHEN PERFORMING ANY MAINTENANCE, YOU MUST FIRST SHUT OFF THE ENGINE, SET THE

PARKING BRAKE, WAIT FIVE (5) MINUTES TO ALLOW PARTS TO COOL AND DISCONNECT THE SPARK

PLUG WIRE, KEEPING IT AWAY FROM THE SPARK PLUG.

Tools Needed:

• Blade Screwdriver

• Eye protection

• Pliers

1. Block the machine up off the ground so that the Front Wheels spin freely.

2. Rotate the Tire so the Key Slot is upward, then pop off the Wheel Lock Ring with a Screwdriver

(Figure 17)

and save it. Remove the Washer and slide the Wheel off.

3. To replace the Wheel, leave the Key in place (if possible) and slide the Wheel back on. If the Key

comes out when you take the Wheel off, put the Wheel back on and rotate it until the Key slots line

up. Slide the Key back in place and reinstall the Washer and Wheel Lock Ring.

Tip: Pliers will help seat the Lock Ring.

NOTE: When replacing the Wheel Lock Ring, make sure the center of the Wheel Lock Ring is opposite the Key.

Figure 17

Wheel Lock Ring
