Contact us at www.DRpower.com 41
Parts List - Handlebar/Controls Assembly
NOTE: Part numbers listed are available through DR Power Equipment. Not all parts appear on all diagrams.
Ref# Part# Description
14 187631 Cable, Brake, 73-1/2"
33 164341 Control Panel
34 161531 Label, Control Panel
54 164301 Frame, Main
55 164311 Handlebar, RH
56 164321 Handlebar, LH
57 164331 Cross Support, Handle
74 110691 Nut, 5/16"-18, ZP
80 110761 Nut, Nylon Lock, 5/16"-18
81 109161 Eyebolt, .625" ID, 5/16"-18 x 4.75"
85 110971 Pin, Spring, 3/16" x 1-3/4"
88 120301 Screw, 3/8"-16 x 1-1/2", Trilobe, Gr2, ZP
99 134431 Bolt, 5/16"-18 x 1-1/2", HCS
115 108871 Lever, Shift, Upper
116 110221 Grip, Shift Handle
158 112391 Washer, Flat, 3/8", USS
161 188251 Wire Harness w/Adapter
188261 Wire Harness w/Adapter and Fuse
163 112051 Switch, w/Key & Hardware, E/S
164 112121 Throttle w/Cable, 43"
168 111631 Screw, #10 x 1-1/2", Type A
170 112441 Washer, 1/2" ID x 3/4" OD
178 164961 Grip, Handlebar, Plain, 1"
179 164951 Grip, Handlebar, Ergonomic, 1"
180 180691 Lever, Operator Presence w/Wire
181 179241 Bracket, w/Mounting holes
183 178971 Screw, Machine, M4 x 22mm
184 165181 Lever, 1", Brake w/Lock
Not Illustrated
112141 Cable Tie, 7-1/2", Black
112261 Tray, Tool, 15" x 18" x 4-1/2"
110151 Frame, Tool Tray
