2.1.3 Scope of delivery
The following components are supplied with the Dräger
DrugTest
®
5000 Analyzer
1)
:
 Dräger DrugTest 5000 Analyzer
 Battery charger power supply (12 VDC) with power cable
 Instructions for Use
2.1.4 Required but not included
Dräger DrugTest 5000 test kits used to collect and analyse
samples.
2.1.5 Optional equipment
Dräger offers additional accessories to expand the system
such as printer, keyboard, bar code reader, carrier bag, 12V
car cable, training test kits and carrying case. Please consult
the order list on Page 7 for additional information.
2.2 Feature description
The Dräger DrugTest 5000 Analyzer prepares the sample
collected with the Dräger DrugTest 5000 test kit and sets the
required reaction temperature. Then it starts analysing the
sample and produces a result at the end of the required
reaction time. The analysis is based on an optical method used
to evaluate the signal intensities of testing and control lines on
the immunochemical test strip contained in the test kit.
The integrated rechargeable battery allows both stationary and
portable use of the Dräger DrugTest 5000 Analyzer.
2.3 Intended use
The Dräger DrugTest 5000 test system consists of the Dräger
DrugTest 5000 Analyzer and the Dräger DrugTest 5000 test
kits. The test system is designed for the simultaneous,
qualitative detection of substances or classes in human saliva
for forensic use.
The detectable substances are defined by the utilised
DrugTest 5000 test kit.
The Dräger DrugTest 5000 test system is a qualitative
measuring system to detect searched substances or their
metabolites which are contained in the sample in excess of a
certain concentration limit (cut-off) and therefore delivers only
a preliminary analytical result (screening method). To obtain a
confirmed analytical result a more specific method must be
used. Gas chromatography/mass spectrometry (GC/MS) is the
preferred method used in most cases.
A professional assessment of the Dräger DrugTest 5000 result
is required allowing for the further clinical consideration of the
test subject. This applies especially if the preliminary result is
positive.
2.3.1 Explanation of symbols
3Menu
The menu is accessed by selecting the key underneath the
»Menu« area when the unit is ready to measure.
Please consult the Dräger DrugTest 5000 System technical
reference manual for additional information.
The menu is navigated with the three unit keys to which
functions are assigned as depicted in the display.
3.1 Menu navigation
Graphic symbols facilitate navigating the menu levels:
3.2 Configuration
The unit can be connected to a PC with the integrated USB
interface. This interface can be used by qualified users and the
technical service of Dräger to change unit settings (e.g. for the
storage of data or the individual allocation of samples). Please
contact Dräger or a service organisation authorised by Dräger
for additional information.
1) Dräger DrugTest is a registered trademark of Dräger.
NOTICE
For Forensic Use only.
i
i
Strictly follow the Instructions for Use!
Manufacturer
Temperature limitation
Expiry date
Separate collection of electric and electronic end-of-life
units
Return to next higher menu level
Closed folder:
This item contains further functions or submenus.
Open folder:
The functions and sub-menus shown here are contained
in this item.
Function:
If activated, functions can be executed in a single step or
several steps.
Selection activated:
Press the key to enable functions that can be selected
and activated.
OK

Dräger DrugTest 5000 Specifications

General

Sample Type	Oral fluid
Display	LCD
Operating Temperature	5 to 40 °C
Storage Temperature	-20 to 60 °C
Detectable Drugs	Cocaine, Opiates, Amphetamine, Methamphetamine, Benzodiazepines, THC
Battery Life	Up to 8 hours
Detection Time	5–10 minutes
