Dräger Flow Check User Manual

13
Fault, Cause, Remedy
Maintenance Intervals
Inspections
At least once a year by specialised service personnel.
Technical Data
Fault Cause Remedy
Apparatus does not
produce smoke.
Air bubble in hose
system,
LED flashing green.
Press button or push
slider until air bubble
is pumped out of the
hose system, see
"Generating smoke",
page 11.
Ampoule empty LED
flashing red
Replace ampoule, see
page 10.
Battery not charged
LED light up red.
Charge or replace
battery, see page 9.
Battery defective. Replace battery, see
page 9.
Hose in hose unit is
clogged.
Remove hose unit.
Place the clogged
section of the hose
between the thumb
and the pointer finger
and roll the clogged
section.
Hose unit defective
LED flashing red.
Replace hose unit,
page 12.
Vaporiser defective. Have vaporiser repla-
ced by Dräger Safety.
Environmental conditions
Operating temperature: –5 to 40
o
C (23 to 104
o
F)
Charging temperature: 0 to 40
o
C (32 to 104
o
F)
Operating time per battery charge: approx. 20 minutes
Smoke time per ampoule: approx. 5 minutes
Battery
Ni-Cd rechargeable batt.: 7.2 V; 1.4 Ah
Order-list
Disposal of electric and electronic appliances
EU-wide regulations for the disposal of electric and electronic
appliances which have been defined in the EU Directive
2002/96/EC and in national laws are effective from August
2005 and apply to this device.
Common household appliances can be disposed of using
special collecting and recycling facilities. However, as this
device has not been registered for household usage, it must not be dispo-
sed of through these means. The device can be returned to your national
Dräger Safety Sales Organization for disposal. Please do not hesitate to
contact the above if you have any further questions on this issue.
Charging current: 700 mA
Dimensions approx. 300 mm x 200 mm x 70 mm
Weight approx. 500 g
CE-Marking Electromagnetic compatibility
(directive 89/336/EEC)
Name and description Order No.
Dräger Flow Check air flow indicator
with one pack of ampoules (3 ampoules and 1 nozzle),
battery pack, packed in plastic case
64 00761
Accessories
Flow Check ampoules
(3 ampoules and 1 nozzle)
64 00812
Battery pack 64 00817
Battery charger – Continental Europe 64 00800
Battery charger – UK 64 00801
Battery charger – USA 64 00802
Adapter cable for in-car recharging 64 00803
Hose unit 64 00818
