INFINITY COCKPIT QUICK REFERENCE GUIDE |14
THIS GUIDE IS INTENDED
FOR REFERENCE
ONLY. REFER
TO
INSTRUCTIONS FOR USE
MANUAL.ADDITIONAL INFORMATION
TO DISCHARGE A PATIENT
1. Select Discharge function key on the main menu bar.
2. The message Caution discharge will delete patient data ap-
pears.
3. Select Discharge to confirm, or Cancel to resume monitoring
same patient.
4. The message Touch Screen to initiate monitoring appears.
Note: All patient data is deleted upon discharge, and either factory or user
default limit settings are restored.
TO PLACE MONITOR IN STANDBY
You can temporarily interrupt patient monitoring by placing the
Cockpit and the M540 in standby mode.
1. Select the Start/Standby... button on the main menu bar to
display the Standby dialog window.
2. Select the Start tab if it is not already selected.
3. Select the Standby button. The banner Standby-Touch Screen
to resume monitoring appears in the center of the Cockpit
screen.
4. To take the Cockpit out of Standby mode, touch the screen to
resume monitoring the vital signs
TO PLACE MONITOR IN PRIVACY
All patient data are removed from the Cockpit and the M540 dis-
plays, but continue to be displayed and alarm signals produced at
the Infinity Central Station.
1. Select the Start/Standby... button on the main menu bar to
display the Standby dialog window.
2. Select the Start tab if it is not already selected.
3. Select the Privacy button. The banner Privacy Touch Screen to
resume monitoring is displayed in the center of the monitor.
