INFINITY COCKPIT QUICK REFERENCE GUIDE |25
THIS GUIDE IS INTENDED
FOR REFERENCE
ONLY. REFER
TO
INSTRUCTIONS FOR USE
MANUAL.ADDITIONAL INFORMATION
Note: Pressing the NIBP start/stop button longer than two seconds suspends
interval mode and sets the Interval time [min] to Off. To resume interval
times, must re-set to desired time interval and initiate by pressing NIBP Start
/ Stop.
TO STOP A NIBP MEASUREMENT
1. Press the NIBP Start / Stop fixed key l
2. To resume interval times, must re-set to desired time interval
and initiate by pressing NIBP Start / Stop.
Mainstream etCO2 Monitoring
CONNECTING THE CO2 SENSOR
1. Connect yellow end of CO2 sensor cable to yellow CO2 con-
nector on M540.
2. Insert correct airway adapter for patient between endo-
tracheal tube adapter and the ventilator Y-piece.
3. Snap the CO2 mainstream sensor firmly onto the airway
adapter and make sure the cable is directed away from the pa-
tient.
Note: Always position the sensor windows of the airway adapter vertically
to prevent patient secretions from obscuring the adapter window.
ADJUST GAS COMPENSATION
Compensates for supplemental O2 greater than 50% N2O or Heliox.
Failure to adjust compensation can cause inaccurate measure-
ments.
1. Select etCO2 parameter box.
2. Select Gas compensation.
3. Dial rotary knob to correct compensation.
4. Click rotary knob to confirm.
