Dräger Infinity Cockpit C700 - SpO2, NIBP, and etCO2 Monitoring

© 2015 Draeger Medic al , Inc .
INFINITY COCKPIT QUICK REFERENCE GUIDE |24
THIS GUIDE IS INTENDED FOR REFERENCE ONLY. REFER TO INSTRUCTIONS FOR USE MANUAL.ADDITIONAL INFORMATION
SpO2 Monitoring
The accuracy of SpO2 monitoring depends largely on the strength
and quality of the SpO2 signal
TO CHANGE PULSE TONE VOLUME
1. Select SpO2 parameter box.
2. At Pulse tone volume %, select button.
3. Dial rotary knob to select desired setting.
4. Click rotary knob to confirm.
TO CHANGE PULSE TONE SOURCE
1. Select SpO2 parameter box.
2. Select Tone Source and select ECG or SpO2.
Note: Refer to M540 Instructions for Use manual for further device specific
information, Masimo or Nellcor.
NIBP - Non-Invasive Blood Pressure
TO START A NIBP SINGLE MEASUREMENT
1. Press the NIBP Start / Stop fixed key .
o Pressing the key again stops the measurement.
o NIBP inflation modes- Adult, pediatric, and neonatal- can be
selected in NIBP parameter box and Settings tab.
TO SET NIBP INTERVAL TIME
1. Select NIBP parameter box.
2. Select Interval time (min).
3. Dial rotary knob to select desired setting.
4. Click rotary knob to confirm.
5. Press NIBP Start / Stop fixed key to initiate cycling.
6. An interval timer bar appears in the parameter box between
interval measurements. This indicates that the interval time
option is in use.
