Invasive Pressures
If no pressure labels are saved as default, labels GP1 to GP4 are
automatically assigned. In Auto view when cables and transducers
are connected IBP parameter box will be visible on Mainscreen.
TO CHANGE A PRESSURE LABEL
1. Select any invasive pressure parameter box.
2. Select Label.
3. Dial rotary knob to select desired label.
4. Click rotary knob to confirm or, if invasive pressure parameter
is not visible
5. Select Sensor parameters… from main menu bar.
6. Select IBP tab to access IBP page.
7. Select desired IBP tab along right side of IBP page.
8. Select Label.
9. Dial rotary knob to select desired setting.
10. Click rotary knob to confirm.
TO ZERO ALL TRANSDUCERS
1. Level transducer stopcocks appropriately for parameters being
zeroed.
2. Close the transducer stopcocks to the patient and open them
to air.
3. Select Zero all key on main menu bar (C700 only), Hemopod,
or QuadHemo.
o Zeroes all transducers open to air sequentially.
Note: All open transducer alarms are silenced for 30 seconds.
TO ZERO AN INDIVIDUAL TRANSDUCER
1. Level transducer stopcock appropriately for parameter being
zeroed.
2. Select parameter box of the desired pressure to zero. Close the
transducer stopcock to the patient and open it to air.
3. Press Zero.
