RRi - Impedance Respiration
TO RELEARN RESP PROCESSING
1. Select RRi parameter box.
2. Select Relearn.
3. RRi waveform is re-analyzed and saved as a reference for
counting the Resp waveform.
TO SELECT AUTO OR MANUAL MODE
1. Select RRi parameter box.
2. At Mode, select Auto or Manual to change.
o Auto – Optimal breath-detection threshold calculated at
the beginning of RESP monitoring, or with RESP Relearn.
Intended for patients with regular breathing patterns. Re-
learn the RRi waveform regularly to reduce artifact and
optimize breath count.
o Manual –The monitor detects breath based on the size of
the waveform. After turning on Manual mode adjust
waveform size. Manual mode is intended for adult or pe-
diatric patients whose breathing patterns show excessive
variation; or for neonates whose breathing rhythms tend
to be irregular, and whose signals may not be reliably de-
tected in Auto mode.
TO ADJUST RRi WAVEFORM SIZE
1. Select RRi parameter box.
2. Select Size % and select desired amplitude.
3. Dial rotary knob to select desired setting.
4. Click rotary knob to confirm.
TO DISPLAY RESPIRATORY MARKERS
1. Select RRi parameter box.
2. At Resp. marker select On or Off.
Note: Respiration markers indicate the time of breath detection. A white
vertical line displays on the Resp waveform where each breath is detected.
