INFINITY COCKPIT QUICK REFERENCE GUIDE |22
THIS GUIDE IS INTENDED FOR REFERENCE ONLY. REFER TO INSTRUCTIONS FOR USE MANUAL.ADDITIONAL INFORMATION
TO TURN PACEMAKER DETECTION ON / OFF
1. Select Heart rate parameter box.
2. Select Settings 2 tab.
3. At Pacer Detection select On or Off.
o If buttons are grayed out, make sure choice of Filter (locat-
ed directly above Pacer detection) is not set to ESU
TO ADJUST QRS DETECTION THRESHOLD
1. Select the Heart rate parameter box.
2. Select Settings 2 tab.
3. Select Normal or Low QRS Threshold
4. Click rotary knob to confirm.
Note – Low detects QRS complexes of low amplitude.
TO SHOW ALL LEADS AND / OR PRINT ECG REPORT
5. Select Heart rate parameter box.
6. Select Show all tab.
7. Select ECG report Print for non-diagnostic report
8. Select Rest ECG report Print for diagnostic report.
o Diagnostic report requires specific software.
TO SELECT NUMBER OF LEADS FOR ARR PROCESSING
1. Select Heart rate parameter box.
2. Select Settings 2 tab.
3. At ARR processing, select ECG 1 or ECG 1 & 2 button
TO RELEARN ECG
1. Select Heart rate parameter box.
2. Select Settings tab > ARR tab > Relearn.
Note: Not available in Neonate Mode
