INFINITY COCKPIT QUICK REFERENCE GUIDE |27
THIS GUIDE IS INTENDED
FOR REFERENCE
ONLY. REFER
TO
INSTRUCTIONS FOR USE
MANUAL.ADDITIONAL INFORMATION
12 Lead Monitoring
Requires an additional 4 lead wire set be added to an existing 6
lead set. The12 lead option must be enabled and patient is admit-
ted at ICS with Name, Height, Weight, and Birth date.
TO OBTAIN A DIAGNOSTIC 12-LEAD (REST ECG) REPORT
1. Select System setup... on the main menu bar.
2. Select the Recordings/ Reports tab.
3. Select Rest ECG report
4. Enter patient gender and race, condition and medications.
5. Press Rest ECG report.
OR
1. Press Menu function key.
2. Press Rest ECG report.
Note: Confirm all leads are free from artifact using the Show all Leads in HR
Menu. REST ECG report tab is available at bottom of screen.
