Dräger Polytron 3000 Instructions For Use

Installing the transmitter
6
Installing the transmitter
Preparing for installation
The performance and effectiveness of the entire system depends essentially on the
position chosen for installing the transmitter.
The following should be noted during installation:
— Local requirements and regulations governing the installation of gas measuring
systems.
— Relevant regulations concerning the connection and routing of electric power
supply and signal lines.
— The full scope of environmental factors to which the transmitter may be exposed
(ambient conditions: see Technical data, page 20).
— Physical properties of the gas to be measured:
For gases with a density lower than that of air, the transmitter must be located
above any possible leak or at the highest point at which large concentrations of
gas may occur.
For gases and vapours with a density greater than that of air, the transmitter must
be located below a possible leak or at the lowest point at which such gases and
vapours may occur.
— The specific uses (e.g. possible leaks, ventilation conditions, etc.).
— Accessibility for the necessary maintenance work (see Installation instructions for
the Polytron docking station).
— All other factors and conditions which could have a negative effect on the instal-
lation and operation of the system (such as vibrations or varying temperatures).
— We recommend installing a reflective shield if the unit is exposed to strong sun-
light.
— The transmitter must be installed vertically (sensor facing downwards).
— The transmitter has been tested with regard to its weather-resistance and may be
installed out of doors. Use of a splash guard is recommended to protect the sen-
sor from splashing water, dust and wind.
The Dräger Polytron 3000 transmitter consists of two main components:
— Dräger docking station
This can be pre-installed anywhere and contains the electrical installation compo-
nents.
— The measuring unit Dräger Polytron 3000
contains the electronics of the transmitter.
If the measuring unit is not fitted immediately after installing the docking station, the
latter should be covered with the raincover provided (dust and water protection) to
protect against dust and splashing water.
In explosion-hazard areas:
Observe the national regulations concerning electrical equipment in
explosion-hazard areas.
