Dräger Polytron 3000 User Manual

Technical Data
20
UL (Underwriters Laboratories Inc.) P3S
Only as to Intrinsic Safety for use in Hazardous Locations
Class I, Div. 1, Groups A, B, C, D
Class II, Div. 1, Groups E, F, G
Use in accordance with Dräger Control Drawing SE20105.
T4: –40 ≤ Ta ≤ +65
o
C, T6: –40 ≤ Ta ≤ +40
o
C.
Not tested in oxygen enriched atmospheres (>21 % O
2
).
Power Supply: V
max
= 30 V, I
max
= 0.3 A, P
i
= 700 mW,
C
i
= 0 nF, L
i
= 50 µH
Meter circuit: V
oc
= 7.6 V, I
sc
= 1 mA, V
max
= 10.4 V, C
a
= 2.5 µF, L
a
= 10 mH,
C
i
= 0, L
i
= 0
CSA (Canadian Standards Associa-
tion)
P3S
Intrinsic safe
Class I, Div. 1, Groups A, B, C, D
Class II, Div. 1, Groups E, F, G
Use in accordance with Dräger Control Drawing SE20106.
Power supply: V
max
= 30 V, I
max
= 0.3 A, P
max
= 700 mW,
C
i
= 5 nF, L
i
= 50 µH
Signal transmission to central unit
Analogue
— Measured-value signal 4 mA to 20 mA
— Drift below zero point 3.8 mA to 4 mA
— Full-scale value exceeded 20 mA to 20.5 mA
— Unit fault <3.2 mA
— Maintenance signal 3.4 mA ±0.2 mA constant
Power supply
Power supply 12 V DC to 30 V DC
Protection against polarity reversal.
Terminals for 0.5 to 2.5 mm
2
(20 to 14 AWG).
Physical specifications
Cable inlet M20x1.5, for cable diameter 6 to 12 mm (0.24" to 0.47")
Dimensions (H x W x D) 166 mm x 135 mm x 129 mm (6.54" x 5.31" x 5.08)
Weight approx. 0.9 kg / 2.0 lbs.
Ambient conditions Specifications for the sensor: see sensor data sheet
for operation –40 to 65
o
C (–40 to 160
o
F)
1)
700 to 1300 hPa (20.7 to 38.4 inch Hg)
0 to 100 % relative humidity, non condensing
1)
The legibility of the display is restricted at temperatures below –20
o
C (–5
o
F).
during storage –40 to 70
o
C (–40 to 150
o
F)
700 to 1300 hPa (20.7 to 38.4 inch Hg)
0 to 100 % relative humidity, non condensing
NRTL/C
®
LR97594
