Page #45 background image
45
Order List Dimensions
Name and description Order-No.
Measuring range 0 ... 100 %LEL
Sensing head Polytron SE Ex PR M1 DD 68 12 711
Sensing head Polytron SE Ex PR M2 DD 68 12 710
Sensing head Polytron SE Ex PR M3 DD 68 12 718
Sensing head
Polytron SE Ex PR NPT1 DD
for conduit-piping 3/4” NPT,
without cable gland
68 12 800
Measuring range 0 ... 10 %LEL
1)
1) The four sensing heads with the identification "LC" (measuring
range 0 ... 10 %LEL) with their corresponding sensors, both the
process adapters and the dust filter were not subject to the part of
the performance test acc. to EN 60079-29-1.
Sensing head Polytron SE Ex LC M1 DD 68 12 722
Sensing head Polytron SE Ex LC M2 DD 68 12 721
Sensing head Polytron SE Ex LC M3 DD 68 12 719
Sensing head Polytron
SE Ex LC NPT1 DD for conduit-piping
3/4” NPT, without cable gland
68 12 801
Measuring range 0 ... 100 %LEL for
high temperatures
Sensing head Polytron SE Ex HT M DD 68 12 720
Accessories
Calibration adapter (PE)
(max. operation temperature 70 °C)
68 06 978
Process adapter
1)
(stainless steel, with locking nut
M30 x 1.5) for DrägerSensor PR M DD
and DrägerSensor PR NPT DD
68 12 470
Process adapter
1)
(stainless steel, with locking nut
M36 x 1.5) for DrägerSensor LC M and
DrägerSensor LC NPT
68 12 465
Dust filter
1) 2)
(10 pcs, PTFE discs)
for DrägerSensor PR M DD and
DrägerSensor PR NPT DD
2) Response times may increase when using the dust filter.
68 10 537
Spare parts
DrägerSensor PR M DD 68 12 220
DrägerSensor PR NPT DD 68 12 380
DrägerSensor LC M 68 10 350
DrägerSensor LC NPT 68 10 675
DrägerSensor HT M DD 68 12 390
W x H x D in mm
Sensing head
Polytron SE Ex PR M1 DD
incl. sensor and cable gland
80 x 130 x 56
Sensing head
Polytron SE Ex LC M1 DD
incl. sensor and cable gland
80 x 145 x 56
Sensing head
Polytron SE Ex PR M2 DD incl.
sensor and sidewise cable gland
136 x 107 x 56
Sensing head
Polytron SE Ex LC M2 DD incl.
sensor and sidewise cable gland
136 x 124 x 56
Sensing head
Polytron SE Ex PR M3 DD
incl. sensor and cable gland
147 x 154 x 75
Sensing head
Polytron SE Ex LC M3 DD
incl. sensor and cable gland
147 x 168 x 75
Sensing head
Polytron SE Ex PR NPT1 DD
incl. sensor
101 x 142 x 75
Sensing head
Polytron SE Ex LC NPT1 DD
incl. sensor
101 x 160 x 75
Sensing head
Polytron SE Ex HT M DD
incl. sensor and cable gland
150 x 152 x 85
