Sensing head Polytron SE Ex PR NPT1 DD
Sensing head Polytron SE Ex LC NPT1 DD
(Diameter of both the wall fixing holes: 7 mm)
Sensing head Polytron SE Ex HT M DD
(Diameter of both the wall fixing holes: 6mm)
A wall fixing hole
02133176.eps
77.8
77.8
110
02233176.eps
125
88
ca.12
88
A
