Dräger PSS BG 4 plus

BG4
Illustrated Parts List
Panorama Nova RP Mask
Item No. Part Number Description Order in
Multiples of
1, 4-28, R53306 Panorama Nova BG4 Mask, EPDM
30-37,40, 41
2-27, 29-37, R53316 Panorama Nova Silicone BG4 Mask
41+42
1 R53066 Mask Body EPDM
2 R50284 Mask Body, Silicone
3 R50833 Polycarbonate Lens
4—21 R50200 Lens w/Wiper
4 R51039 Lens, Wiper, BG Mask
5 R50436 Rubber Insert, BG Mask 5
6 R20111 Seal Ring 5
7 R20110 Slide Ring 20
8 R20108 Nut, Panorama Nova 25/25T Mask
9 M12165 O-Ring, BG Mask 10
10 R20105 Shaft, BG Mask
11 R20109 Wiper Lever, BG Mask
12 M09527 Disc 10
13 (1336142)* M3X4 DIN 921-A4
14 R20106 Wiper Bushing, BG Mask
15-18 R23551 Wiper Rep. Set
15 (R50199)* Wischer, Vollst.
16 (1337289)* M1,6 DIN 934-M A4
17 (R50814)* Distanzstueck
18 (1337270)* DIN 84-AM1,6X8-A4
19 (R50201)* Druckbuegel, UGR
20 (R50202)* Feder
21 (R50203)* Wischertraeger
22-24 R23117 Frame with Parts
22 R50146 Frame, Mask
23 1341308 Recessed Head Screw M4X20 10
23.1 (1275224)* Mask Screw
*Part Numbers in Brackets () Not Available
Page 103
Draeger Training 11/16 rev 1
