Dräger PSS BG 4 plus

BG4
Illustrated Parts List
Panorama Nova RP Mask
Item No. Part Number Description Order in
Multiples of
24 1336002 Locknut 20
25 RM08910S Stud Pkg 15
26 R52184 Sliding Ring for R52185 10
27 R52185 Clamp 10
28 R53331 Inner Mask EPDM, BG
29 R50731 Inner Mask, Silicone, BG-4
30 R53179 Gusset 10
31-37 R53305 Connecting Piece, Mask BG-4
31 R52816 Retainer, Speech Diaphragm 10
32 R51102 Diaphragm, Speech 4
33 T10549 O-Ring, Speech Diaphragm 10
34 R53305 Connecting Piece for BG-4 Mask
35 R28383 Housing 10
36 R28385 Spring 10
37 R28384 Key 10
31-39 (R53304)* Maskenanschluss RP-T
38 (1330810)* Din 84-AM3X6-A4
40 R26279 Head Strap, EPDM
41 R52643 Sliding Buckle 10
42 R50282 Headstrap, Silicone
43 R26770 Headstrap, BG-ZT
45
R20685 Screw
46
R20686
Pressure Plate
47
K
nob (R20687)*
K
nob
48
Disc (R21382)* Disc
49
50
*Part Numbers in Brackets () Not Available
Page 104
Draeger Training 11/16 rev 1
