X-plore 8000 9
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and
receiver.
 Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician
for help.
2.7 Symbol explanation and type identical
labels
2.7.1 Name plates
► Illustration of name plates on page 4
1 Product name
2 International Protection Code
3 Fulfilled standards
4 Symbol "Follow instructions for use"
5 WEEE symbol "Separate collection of electrical and
electronic equipment"
6 Country of production
7 Manufacturer
8 CE marking
9 DataMatrix code with part and serial number
10 Serial number
11 Product code
12 Only for indoor use, not for outdoor use
13 Maximum ambient temperature
14 Electrical data
15 Pin assignment
16 Recycling symbol
17 Warning notice
Information on year of manufacture
The year of manufacture results from the 3rd letter of the serial
number: F = 2014, G = omitted, H = 2015, I = omitted, J = 2016,
K = 2017 etc.
Example: Serial number ARFH-0054: The third letter is F, the
year of manufacture is therefore 2014.
2.7.2 Packaging
3Use
3.1 Preconditions for use
 The ambient conditions (in particular type and
concentration of the contaminants) must be known.
 The oxygen content of the ambient air must not drop below
the limit value of at least 19.5 vol.% oxygen.
Observe the national guidelines in other countries.
3.2 Preparations for use
Blower unit: Figure H
Rechargeable battery: Figure I
Standard battery charger: Figure J
Follow the instructions for use
Maximum storage area humidity
Storage temperature range
WARNING
Fire hazard due to sparks or liquid metal splashes!
 Always use powered air purifying respirators with a
particle or combination filter with additional prefilter
if sparks or liquid metal splashes may occur during
use.
 Replace the prefilter at regular intervals; at least
once per shift, but in case of visible saturation at
the very latest.
 Replace particle and combination filters as soon as
they are visibly saturated with dust even if the
residual capacity indicator of the powered air
purifying respirator indicates that the residual
capacity is still sufficient.
 Avoid direct contact of sparks and liquid metal
splashes with the powered air purifying respirator:
Contact of a heavily saturated prefilter, particle or
combination filter with sparks or liquid metal
splashes can cause damage to the filter or ignite
the collected particles.
WARNING
Ambient air penetration!
Incorrect assembly of the components can impair the
device function.
For rechargeable battery, splash guard cover, and
chemical cartridge or combination filter ensure that:
 Both connection points engage into the intended
sockets when inserted
 The respective components do not get jammed
when they snap into place
≤95%
-20°C
+60°C
!
!

Dräger X-plore 8000 Specifications

General

Product Type	Powered Air-Purifying Respirator (PAPR)
Protection Class	TH3
Charging Time	Approximately 4 hours
Air Flow	Minimum 170 l/min
Display	LCD with status information
Filter Type	Particle filters, gas filters, or combination filters (depending on the application)
Alarm	Visual and audible alarms for low battery
Approvals	EN 12941
Battery Life	Up to 4-20 hours (depending on battery and operating conditions)
