Section 8 - Dimensions
12"
(305mm)
8"
(203mm)
2"
(51mm)
Series E
Viewing
Surface
* - Case support brackets will be evenly spaced along the case.
Varies
Series V
Viewing
Surface
*Please Note: Optional wall brackets add 1
" per bracket to case length. Wall mounting
bracket hole location is 1" from end of case.
13"
2"
(57mm)
2"
(57mm)
1"
(35mm)
1"
3"
(98mm)
3"
(54mm)
2"
(51mm)
2"
(51mm)
5"
(127mm)
(25mm)
2"
2"
2"
3"
(83mm)
3"
" dia.
(13mm)
" dia.
Optional Wall
Mounting Bracket
Case Width
Number of
Intermediate Brackets
< 96"
(< 2.44m)
0
> 96" and < 180"
(> 2.44m and < 4.57m)
)
1
> 180" and < 240"
(> 4.57m and < 6.1m)
)
2
> 240" and < 346"
(> 6.1m and < 8.8m)
)
3
Brackets are equally spaced from each other and each end.
For example, if the case length is 202"
(5.13m)
, then each of the two
brackets will be placed approximately 67.33"
(1.71m)
from each end
[with 67.33"
(1.71m)
between them].
page 7 of 7
Paragon E & V
