Vigor130 Series User’s Guide
30
Available settings are explained as follows:
Item Description
Enable/Disable
Click Enable for activating this function. If you click Disable,
this function will be closed and all the settings that you
adjusted in this page will be invalid.
DSL Modem Settings
Set up the DSL parameters required by your ISP. These are
vital for building DSL connection to your ISP.
Multi-PVC channel - The selections displayed here are
determined by the page of Internet Access >>
Multi-PVC/VLAN.
VPI - Type in the value provided by ISP.
VCI - Type in the value provided by ISP.
Encapsulating Type - Drop down the list to choose the type
provided by ISP.
Protocol - Drop down the list to choose the protocol, PPPoE or
PPPoA.
Modulation – Choose a suitable method for PPPoE/PPoA
connection.
PPPoE Pass-through
The modem offers PPPoE dial-up connection. Besides, you
also can establish the PPPoE connection directly from local
clients to your ISP via the Vigor modem. When PPPoA
protocol is selected, the PPPoE package transmitted by PC will
be transformed into PPPoA package and sent to WAN server.
Thus, the PC can access Internet through such direction.
For Wired LAN – If you check this box, PCs on the same
network can use another set of PPPoE session (different with
