8 9
ENEN
2-in-1 Charging & Storage Mount Installation Diagram
(The 2-in-1 charging & storage mount is an optional accessory. You can install it based on your needs.)
*30cm: Leave enough space just in case you may
need to purchase the replaceable battery in the
future.
• The bottom of the mounting template sticker should be level and at least 103cm from the ground.
The top should have at least 30cm* of clearance above it.
• Use a power drill with an 8mm drill bit to drill a hole into each marker on the mounting template
sticker, then insert a wall plug into each hole.
• Align the locating holes on the mount with the holes on the wall. Fasten it to the wall with the
included screws.
Note: The 2-in-1 charging & storage mount should be installed in a cool, dry place with an electrical
outlet nearby. Prior to installing, ensure that there are no electrical wires or pipes in the space directly
behind where the mount will be installed.
Installation
103 cm
30 cm
Charging
Note: Once the vacuum is fully charged, the
indicator will turn o after 5 minutes, and the
vacuum will enter energy-saving mode.
Charging the vacuum with the charger Charging the vacuum on the charging mount
Charging Methods
1
2
LED Battery Status IndicatorDisplay Screen
Battery Status Display
When charging, the indicators blink white. When
the charging is completed, the indicators keep
solid white.
The number on the display screen represents
the current battery level in a percentage during
charging. When the number becomes 100, the
battery is fully charged.
Fully charge the vacuum before using it for the rst time.
• A full charge will take approx. 4 hours.
• Vacuuming in Turbo Mode for a prolonged period will cause the battery to heat up, which increases
charging time. Allow the vacuum to cool down for 30 minutes before charging it.
Note:
