-8-
(2) After changing data
* FUNCTION SET *
(00)Ref (Set).F
60.0 [Hz}
Change data, then press the SET key.
The lowest display disappears, and new data
appears.
Code
Numbe
Display on LCD Descriptions
Set ranges
(Selection
items)
Standard
factory set
data
Setting
resolution
Units
Rewriting
in
operation
Remarks
00 Ref(Set).F Set frequency
-Top.F
Top.F
0.0 0.1 Hz O
01 FOR-JOG.F
Forward jogging
frequency
0.0
30.0
5.0 0.1 Hz O
02 REV-JOG.F
Reverse jogging
frequency
0.0
30.0
5.0 0.1 Hz O
03 Preset1.F Preset frequency 1
-Top.F
Top.F
0.0 0.1 Hz O
04 Preset2.F Preset frequency 2
-Top.F
Top.F
0.0 0.1 Hz O
05 Top.F Max. frequency
Fmax
400.0
(Note 1)
60.0 0.1 Hz X
Fmax means the maximum of
Ref(Set).F, PC-Base.F and other set
values whose upper limit is Top.F
06 PC-Base.F
Power control
(base) frequency
30.0
Top.F
60.0 0.1 Hz X
07 Rated Out.V
Rated output
voltage
280-500
140-250
400
200
1
1
V
V
O
O
Depends on the 400V and 200V classes
08 Accl.Time
Acceleration time
(1)
0.1
3600.0
30.0 0.1 sec X
09 Decl.Time
Deceleration time
(2)
0.1
3600.0
30.0 0.1 sec X
10 Torq.Boost
Torque boost
volume
0.0-20.0 0.0 0.1 % O
11 Min F Min.frequency 0.0-10.0 0.5 0.1 Hz O
12 OL.Set
Setting overload
ratio
80-110 100 1 % O
13 V/F Pattern
V/F pattern
selection
Linear Sqr-Law
Bend
Linear X
Linear: V/F linear
Sqr-Law: V/F square reduction
Bend: V/F folded line
14 Start.Mode
Start mode
selection
Min.F start
Free start
Min.F
start
X
Min.F start: Starting at minimum
frequency
Free start: Free starting
15 Stop.Mode
Stop mode
selection
Decel stop
Free stop
Decel
stop
X
Decel stop: Stopping after
deceleration
Free stop: Free stopping
16 Function.up
Expanded set item
selection
Sp.set-1
Sp.set-2
Option
Sp.set-1 O
For selecting items 17 and after.
See the application manual.
2.3.3 Set data code list (Items selectable in function mode)
Note 1: When changing the set data of code number 05 "Top.F (maximum frequency)", also
change the over-frequency in the following procedures:
Select code number 16 "Expanded set item selection" to select.
Sp.set-1. Display code number 21 OF.Set. Change data to a value higher than the
setting of code
05 Top.F with the SET and numeric key entry.
2.3.4 Data recording
(1) When data of each function has been set, it should be protected as shown in 2.5 below.
(2) We recommend that function data be stored separately, before maintenance work, in order to
prevent the data from being lost due to unexpected accidents.
