Drivecon VF61 - Standard Specifications

7.4 Standard Specifications
*1 Motor is general purpose type with 4 poles, in case of larger size motor, more than 75 HP, please refer to
Drivecon.
*2 Output voltage can not exceed input AC voltage.
*3 Varies depending on impedance value of power supply.
-20-
Model VF61-
200V Series
2R22 3R72 5R52 7R52 1122 1522 2222 3022 3722 4522 5522
Rated
output
Motor (HP) *1
3 5 25 10 15 20 30 40 50 60 75
Capacity
(kVA)
4.0 6.8 9.5 12.9 18.3 24.8 34.6 48.1 58 73.6 88.3
Current (A)
10 17 24 32.5 46 62.5 87 121 146 185 222
Voltage (V)
200~230V (according to input voltage)*2
Input
Rated
voltage/freq.
3 phase 3 wires
200~230V +/- 10% 50/60 Hz +/- 5%
Input power
factor
Approx. 0.7 (without DCL) More than 0.9 (with DCL) *3
Input capacity
(kVA)
4.4 7.5 10.4 14.9 20.1 27.2 38.0 52.9 63.8 80.9 97.3
DC Reactor
Option 1522 2222 3022 3722 4522 5522
Cooling method
Forced cooling
Model VF61-
400V Series
2R24 3R74 5R54 7R54 1144 1544 2244 3044 3744 4544 5544
Rated
output
Motor (HP) *1
3 5 7.5 10 15 20 30 40 50 60 75
Capacity(kVA)
4.4 7.3 10.3 13.5 19.1 25.8 36.6 49.7 60 73.3 83.3
Current (A)
5.5 9.2 13 17 24 32.5 46 62.5 75.5 92.5 111
Voltage (V)
380~460V (according to input voltage)*2
Input
Rated
voltage/freq.
3 phase 3 wires
380~460V +/- 10% 50/60 Hz +/- 5%
Input power
factor
Approx. 0.7 (without DCL) More than 0.9 (with DCL) *3
Input capacity
(kVA)
4.1 7.0 10.3 14 20.5 28 40.2 54.6 60 80.9 91.6
DC Reactor
Option 2244 3044 3744 4544 5544
Cooling method
Forced cooling
