DROPSA BRAVO - Pump Components; Bravo Grease Pump Components; Bravo Oil Pump Components

5
5. PUMP COMPONENTS
BRAVO GREASE
BRAVO OIL
Stirrer device with wiper
Modular Reservoir (3
max)
Pump Element 1
Refilling point grease
nipple
Control Panel
(automatic version)
Connection point for
Pump element 3
1/8BSP Return Port
Connection point for
Pump element 2
Connector plate
Filler Cap
Auxiliary Return Ports
1/8BSP
Warranty seal
