7.5.4 Operation mode – Automatic version Mode OFF
7.6 PROGRAMMING THE ELECTRICAL CONTROLLER
PROGRAMMING SEQUENCE
STEP
BUTTONS
OPERATION
1
hold for 5 seconds.
Enter programming mode
2
or
Select PARAMETER to change
3
Confirm the selection and view the current value
4
or
Increment/Decrement VALUE/SETTING of PARAMETER
5
Confirm value/setting and return to menu
6
hold for 2.5 seconds.
Save settings and exit programming mode
NOTE:
When power is removed from the Bravo, the electronic control will save the cycle condition in memory. When
power is reapplied the controller will resume the logic from exactly the same point (unless the PRELUBE option is
set).
When powering on the system or when pressing the RESET button the display will the firmware version of the unit
for 2 seconds.
For all modes the Prelube parameter determines if the pump starts in a lubrication cycle when it is set to ON.
Cycle and Pause inputs consider one complete cycle when the input returns to its original state at the time of cycle.
For example, if the switch is in the ON state at the start of the lubrication cycle then it must change state to OFF,
and then back to ON to count as one cycle.
Pump operates when external signal is given. No monitoring
NOTE: To modify the operating parameters repeats steps 2 to 5 for all necessary values and then follow
step 6 to save and exit.
During programming mode, if no button is pressed for 20 seconds, or alternatively UP or DOWN
arrows are held for 2.5 seconds, this will exit Programming mode without saving the values.
