DSC LE2080 Installation Guide

ATS Custom Category C Level
EN50136-1:2012 +A1:2018 Table2 – Transmission time SPTaccording to SP4 and DP3
EN50136-1:2012 +A1:2018 Table3 – MaximumReporting Time SPTaccording to SSPT according to SP4 and DP3P4 and DP3
EN50136-1:2012 +A1:2018 Table7 – ATSN availability SPTaccording to SP4 and DP3 (depending on cellularcarrierused)
EN50136- 1:2012 + A1:2018 Table 8 – SPT substitution security
requirements
SPTaccording to SP4 and DP3(useAES-128 and authentication/sequential
information in each message transmitted to the SGreceiver)
EN50136- 1:2012 + A1:2018 Table 9 – SPT information security
requirements
SPTaccording to SP4 and DP3 (useAES-128 encryption)
EN50136-1:2012 +A1:2018 Table1 – ATSconfiguration
Use single communication path for models 3G2080 (R)E- EU/LE2080- EU
(cellularnetwork), TL280(R)E(Ethernet port)(SPTaccording to SP4)and two
communication paths for model TL2803G (R) E- EU/TL280LE- EU
(cell/Ethernet). (SPT according to SP4 orDP3)
EN50136-1:2012 +A1:2018 Table4 – RCTto AEalarmreporting ATSfailure reported to ARC, SPTaccording to SP4 and DP3
EN50136-1:2012 +A1:2018 Table5 – SPTto ASalarmreporting
ATS failure reported to AS (DSC compatible control panel
HS2128/HS2064/HS2032/HS2016).SPT according to SP4 and DP3
EN50136-1:2012 +A1:2018 Table6 – ATSavailabilityrecording There isno recording of availabilityfailure
EN50136-2:2013 Table 1 No logging function provided
EN50136-2:2013 Table 2 No memoryprovided forlogging function
EN50136-2:2013 Table 3 ATSfailure reported to ARC
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby, Tyco Safety ProductsCanada Ltd declaresthat the radio equipment type isin compliance with Directive2014/53/EU. The fulltext of the EU declar-
ationsof conformityforthe modelsmentioned below are available at the following internet addresses:
TL2803G(R)E-EU -http://dsc.com/pdf/1605003
3G2080(R)E-EU -http://dsc.com/pdf/1605004
TL280LE-EU -http://dsc.com/pdf/2112001
LE2080-EU -http://dsc.com/pdf/2112002
Operating frequency bands and related max radio-frequency power transmitted:
NOTE:The compatiblereceiverat ARC location shallhave supervision window programmed for180 seconds.TL2803G(R)E-EU/3G2080(R)E-EU/TL280 (R)
E/ TL280LE-EU/LE2080-EU has been certified by TELEFICATION in accordance with EN50131-1:2006/A2:2017, EN50131- 10:2014 requirements for
Grade 2, ClassII and EN50136-2:2013 ATSCustomCategoryC according to SP4 and DP3.
Frequency Band Maximum Power
EGSM900 890.0MHz- 914.8MHz Class4 (2W)@ 900MHz, GSM
EGSM900 880.2MHz-889.8MHz Class1(1W)@ 1800MHz,GSM
DCS1800 1710.2MHz-1784.8MHz ClassE2 (0.5W)@ 900MHz,EDGE
WCDMA(Band VIII)882.4MHz- 912.6MHz ClassE2 (0.4W)@ 1800MHz, EDGE
WCDMA2100 (Band I)1922.4MHz-1977.6MHz Class3 (0.25W)@ 900/2100MHz,WCDMA
LTE25dBm Class3@700(FDD28)/800(FDD20)/900 (FDD8)/1800(FDD3)/2100(FDD1)/2600(FDD7)MHz
OnlymodelsTL2803GRE-EU, TL2803GE-EU, 3G2080RE-EU, 3G2080E-EU,TL280LE-EU and LE2080-EU are CEcompliant.
European single point of contact: TycoSafetyProducts,Voltaweg 20, 6101XK, Echt,Netherlands
UL/ULC Installation Requirements
NOTE:Forequipment used at the protected premisesand intended to facilitate IPcommunications(hubs,routers, NIDs,DigitalSubscriberLine (DSL), cable
modems),24 hourbackup powerisrequired. Where such cannot be facilitated, a secondary(back-up)communication channelisrequired.
Domain Name Service (DNS) programming is not permitted in UL1610 listed systems.
Technical Specifications
The input voltage to the Communicatorcan be drawn fromthe UnderwritersLaboratories/UnderwritersLaboratoriesCanada (UL/ULC)listed controlpanel.
Notes for using Private, Corporate, and High Speed Data Networks:
Networkaccessand domain access policiesshall be set to restrict unauthorized network access,and spoofing or Denialof Service (DoS) attacks. Select an
Internet Service Provider (ISP) that has redundant servers/systems, back-up power, routers with firewalls enabled, and methods to identify and protect
againstDoSattacks(e.g., viaspoofing).
Notes for using Public Switched and Cellular Data Networks:
Communication channels shall be facilitated such that the communicator willrestrict unauthorized access,which could otherwise compromise security. The
communicatorshallbe located in a secured area.
•ForULC Residential Fire and Burglary applicationsthe TL2803G(R)E/3G2080(R)E/TL280(R)E/LE2080(R)/TL280LE(R)can be used asprimary com-
munication channel via either cellular or Ethernet or as a back-up in conjunction with the Digital AlarmCommunicator Transmitter(DACT). Test transmission
every24 hoursshallbe enabled on each channel.
•ForULC Commercial Fire and Burglary applicationsthe TL2803G(R)E/3G2080(R)E/TL280(R)E/LE2080(R)/TL280LE(R)can be used asa passive
communication module with the following securitylevels:
l P1 (eachchannelcellularorEthernet isindependent)
l P2 (cellularand Ethernet in back-up configuration, panelsection [851][005] toggleoption [5] OFF).
l P3 (cellularand Ethernet in redundant configuration, panelsection [851][005] toggleoption [5] ON).
The communicator can also be used as an active communication systemwith the security levels A1-A4 (each channelcellular or Ethernet independent or
togetherin a back-up/redundant configuration). For active line security systemsAES128 bit encryption shallbe enabled (at the monitoring station receiver)
and the supervision heartbeat rate shallbe set as90 seconds(panel section [851][004] = 005A/90). The supervision window at the SignalReceiver Center
(SRC)'sreceivershallbe programmed asmaximumof180 (00B4/180)seconds.
NOTE:ForULC commercialfire passive communication, encryption shallbe enabled,
•ForUL Residential Fire and Burglary applications the TL2803G(R)E/3G2080R/TL280(R)E/LE2080(R)/TL280LE(R)can be used asthe primary com-
munication channelvia eithercellularorEthernet, orasa back-up in conjunction with the DACT(30 daytesttransmission isrequired on eachchannel).
24
