DSC LE2080 Installation Guide

Regulatory Information
Modification Statement
DigitalSecurity Controlshas not approved anychanges ormodifications to this device by the user. Anychanges ormodifications could void the user’s
authorityto operate the equipment. DigitalSecurityControls n’approuve aucune modification apportée à l’appareilpar l’utilisateur, quelle qu’en soit la
nature. Tout changement ou modification peuvent annuler le droit d’utilisation de l’appareilpar l’utilisateur.
Interference Statement
Thisdevice complieswith Part 15 of the FCC Rulesand Industry Canada licence-exempt RSSstandard(s). Operation issubjectto the following two con-
ditions:(1) thisdevice maynot cause interference,and (2)this device must accept anyinterference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareilsradio exempts de licence. L'exploitation est autorisée aux
deuxconditions suivantes : (1)l'appareil ne doit pasproduire de brouillage, et (2) l'utilisateurde l'appareildoit acceptertout brouillage radioélectrique
subi, même sile brouillage est susceptible d'en compromettre le fonctionnement.
Wireless Notice
Thisequipment complieswith FCC and IC radiation exposure limitsset forth for an uncontrolled environment. The antenna should be installed and oper-
ated with minimumdistance of 20 cm between the radiator and yourbody. Thistransmittermust not be co-located oroperating in conjunction with any
otherantenna ortransmitter.
Cet appareilest conforme auxlimitesd'exposition aux rayonnementsde la IC pourun environnement non contrôlé. L'antenne doit être installé de façon
à garder une distance minimale de 20 centimètres entre la source de rayonnementset votre corps.L'émetteurne doitpas être colocalisé ni fonctionner
conjointement avec à autre antenne ou autre émetteur.
Antenna gain mustbe below /Gain de l'antenne doit être ci-dessous:
Frequency Band/Bande de fréquence TL2803GRE, TL2803GE, 3G2080RE, 3G2080E TL280LE, TL280LER, LE2080, LE2080R
GSM850 / FDD V 2.26 dBi -
PCS1900 / FDD II 2.41 dBi -
LTEB2 - 2.76 dBi
LTEB4 - 2.82 dBi
LTEB5/ B12 / B13 - 2.45 dBi
FCC Class B digital device notice
Thisequipment has been tested and found to complywith the limits for a ClassBdigital device, pursuant to part 15 of the FCC Rules. Theselimits are
designed to provide reasonable protection against harmfulinterference in a residential installation. Thisequipment generates usesand can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may causeharmful interference to radio communications.
However,there is no guarantee that interference willnot occurin a particular installation. If thisequipment does cause harmfulinterference to radio or
television reception, which can be determined byturning the equipment off and on, the userisencouraged to tryto correct the interference byone or
more of the following measures:
-Reorient orrelocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different fromthat to which the receiver isconnected.
-Consultthe dealeroran experienced radio/TVtechnician forhelp
CAN ICES-3 (B) / NMB-3 (B)
TL2803G(R)E -EU /3G2080(R)E- EU/TL280(R)E
LE2080(R)/TL280LE(R)
FCC ID:F5316TL2803GRE FCC ID:F5317TL280LER
IC: 160A-TL2803GRE IC:160A-TL280LER
Notes for EN50131-1:2006/A1:2009 Compliant installations:
ModelsTL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)E/TL280LE-EU/LE2080-EUare an SPTType Y.The module ismounted within CIEorPS housing
and itreceivespowerfromthe compatible CIEorPowerSupplysource that arein compliance with EN50131-6:2017 Type Arequirementsfora Grade 2,
ClassIIapplication. This product hasno replacement partsand software programmable optionsare accessibleat level3 (installermode),section [851].
The TL2803G(R)E-EU/3G2080 (R)E-EU/TL280 (R)E/TL280LE-EU/LE2080-EUconnectsto compatible DSCalarm controlpanelsusing the DSC pro-
prietaryserial interface and protocol PC-Link(converted also to RS-422). The module operates in pass-through mode and it does acknowledge the
alarmto the compatible controlpanelafteran acknowledgement hasbeen received fromthe compatible alarmreceiver
1.The TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)E/TL280LE-EU/LE2080-EUmodule ismonitored bythe controlpaneland itisprogrammed via the
programming menu (* 8, section [851] in the control panel. The interface is connected to the PC-Link busas shown in the diagram included in this
manual.
2.The HSPA3G/LTECellularpath isimmune to conducted and radiated RFfieldswith levelsup to 10V/mastested perEN50130-4 Standard.
3.The TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)E/TL280LE-EU/LE2080-EU module conforms with radiated emissions levels forClass B equip-
ment asper standardsEN61000-6-3/EN55022/CISPR32.
4.The TL2803G(R)E-EU/3G2080(R)E-EU/TL280 (R)E/ TL280LE-EU/LE2080-EU module uses AES128 encryption and heartbeat supervision for
HSPA3G LTE Cellular communication paths and it meets security levels S2 as per EN50136-2:2013. It also uses authentication for each message
exchanged with the compatiblereceiverequipment atARC and it meetsleveI 2 forinformation security.
5. The 3G2080 (R) E- EU/LE2080-EU module has only one communication path: HSPA3G or LTE Cellular communication path using
900/1800/2100MHzor LTE PublicCellular Network. The HSPA3G/LTE Cellular communication path that can be used in a standalone mode in con-
junction with a DSCalarmsystem(compatible DSCalarmcontrolpanelmodels:HS2128/064/032/016). The supported ATSconfiguration is: SP4.
6.The TL280(R)Emodule hasonlyone communication path:Ethernet communication path using Internet. The communication path that can be
used in a standalone mode in conjunction with a DSCalarmsystem(compatibleDSCalarmcontrolpanelmodels:HS2128/064/032/016).
The supported ATSconfiguration is:SP4.
7.The TL2803G(R)E-EU/TL280LE-EU module hastwo communication paths: HSPA3G/LTECellularcommunication path using 900/1800/2100MHz
LTEPublic Cellular Networkand Ethernet communication path using Internet. The communication paths can be used in a standalone mode in con-
junction with a DSC alarm system (compatibleDSC alarm control panel models: HS2128/064/032/016). The supported ATS configuration is:SP4 or
DP3.
8.TL2803G(R)E-EU/3G2080 (R)E-EU/TL280(R)E/ TL280LE-EU/LE2080-EU has been tested for compliance in conjunction with the following applic-
able standards:EN50136-1:2012 + A1:2018, EN50136-2:2013, EN50131-10:2014, ATSconfiguration: SP4, DP3
ForEN50131-1:2006/A2:2017 compliant installations,the following programming optionsshallbe setasdescribed. Supervision Heartbeat: shallbe set
to 180 seconds
23
