Band Transmit Band (Tx) Receive Band (Rx)
LTE B1 1920 - 1980 MHz 2100 - 2170 MHz
LTE B3 1710 - 1785 MHz 1930 - 1990 MHz
LTE B7 2500 - 2170 MHz 2620 - 2690 MHz
LTE B8 880 - 862 MHz 791 - 821 MHz
LTE B28A 703 - 733 MHz 758 - 788 MHz
WCDMA B1 1920 - 1980 MHz 2110 - 2170 MHz
WCDMA B3 1710 - 1785 MHz 1805 - 1880 MHz
WCDMA B8 880 - 915 MHz 925 - 960 MHz
2G DCS1800 1710 - 1785 MHz 1805 - 1880 MHz
2G EGSM 900 880 - 915 MHz 925 - 960 MHz
Table 3: 3G Global - UE910-NAR/EUR and HE910-EUR
Band Transmit Band (Tx) Receive Band (Rx)
WCDMA B1 1920 - 1980 MHz 2110 - 2170 MHz
WCDMA B2 1850 - 1910 MHz 1930 - 1990 MHz
WCDMA B3 1710 - 1785 MHz 1805 - 1880 MHz
WCDMA B8 880 - 915 MHz 925 - 960 MHz
PCS 1900 1850.2 - 1909.8 MHz 1930.2 - 1989.8 MHz
DCS 1800 1710 - 1785 MHz 1805 - 1880 MHz
GSM 850 824.2 - 848.8 MHz 869.2 - 893.8 MHz
EGSM 900 880 - 915 MHz 925 - 960 MHz
References to model names TL280(R)E, TL2803G(R)E, 3G2080(R)E,TL280LE(R) and LE2080(R) throughout
this manual apply to all specified models unless stated differently. Models ending in “R” include a built-in RS-232
interface for connecting to local third-partyapplications.
3G2080(R)E: Isa HSPA(3G) cellular alarm communicator that sends alarm communication to Sur-Gard System I-
IP, II, III (SG-DRL3IP), IV (SG-DRL4IP), and 5 (SG-DRL5IP) central station receivers via a HSPA(3G)/GPRS digital
cellular network. TL2803G(R)E: Is a dual-path HSPA(3G) Ethernet alarm communicator that sends alarm com-
munication to Sur-Gard System -IPI, II, III, IV, and 5 central station receivers through Ethernet/Internet or a HSPA
(3G)/GPRS digital cellular network.
TL280(R)E: Is an Ethernet alarm communicator that sends alarm communication to Sur-Gard System I-IP, II, III
(SG-DRL3IP), IV (SG-DRL4IP), and 5 (SG-DRL5IP) central station receivers via Ethernet/Internet.
LE2080(R): is an LTE (4G) cellular alarm communicator with HSPA(3G) fallback support that sends alarm com-
munications to Sur-Gard System I-IP, II, III(SG-DRL2IP, IV (SG-DRL4IP) and 5 (SG-DRL5IP) central station receiv-
ers via an LTE(4)/HSPA(3G) digital cellular network.
TL280LER: Isa dual path LTE (4G) Ethernet alarm communicator that sends alarm communications to Sur-Gard
System I-IP, II, III (SG-DRL3IP, IV (SG-DRL4IP) and 5 (SG-DRL5IP) central station receivers via Ethernet/Internet
or a LTE(4)/HSPA(3G) digital cellular network.
The communicator can be used as either a backup or primary communicator. The communicator supports Internet
Protocol (IP) transmission of panel and communicator events over Ethernet/Internetand/or HSPA/GPRS.
The cellular performance of the LE2080(R), TL280LE(R), 3G2080(R)E or TL2803G(R)E communicators depend
greatly on the LTE(4G)/HSPA(3G) network coverage in the local area. A communicator placement test must be per-
formed prior to mounting the unit . A minimum of one green LED must be ON for good signal strength. Optional
3G/2G and LTE/3G antenna extension kits are available to improve signal strength if required. GS-15ANTQ, GS-
25ANTQ and GS-50ANTQ kits are available for 3G/2G products and LTE-15ANT, LTE-25ANT,LTE-50ANT exten-
sion kits are available for LTE/3G products.
NOTE: Prior to installation, confirm with the local service provider that the network is available and active in the
area where the communicator will be installed, and that radio signal strength (CSQ) is adequate.
Panel Mounting
The following communicators are compatible with HS2016, HS2016-4,HS2032, HS2064, and HS2128 panels:
l
3G2080(R)E (HSPA(3G)/GPRS only)
l
TL2803G(R)E (Ethernet/Internet + HSPA(3G)/GPRS dual-path)
l
TL280(R)E (Ethernet/Internet only)
l
LE2080(R) (LTE(4G)/HSPA(3G) only)
l
TL280LE(R) (Ethernet/Internet + LTE(4G)/HSPA(3G))
5
