Model
3G2080(R)E/LE2080(R)
Cellularonly
TL280LE(R) /TL280LE-EU
/ TL2803G(R)LE2080(R) /
LE2080-EU /3G2080(R) /
TL280(R)E
Internet and Cellular
TL2803G(R)E/TL280LE(R)
Internet and Cellular
Power Supply Ratings
Input Voltage
10.8-12.5 VDC
Power is supplied from the panel’s PC-Link header or a PCL-422 module in
remote cabinet installations. In remote cabinet installations, the PCL-422 module
located with the communicator is powered by either an HSM2204 or an HSM2300.
Refer to the PCL-422 installation instructions for details.
Current Consumption
Standby Current 90mA 100mA 120mA
Alarm (Transmitting)
Current
400mA
Operating Frequency 850MHz, 900MHz, 1800MHz, 1900MHz, 2100MHz
Typical Antenna Gain
See page 23
Environmental Specifications
Operating
Temperature
-10°C to 55°C (0°C to 49°C for UL/ULC)
Humidity 5% ~ 93% relative humidity, non-condensing
Mechanical Specifications
Board Dimensions
(mm)
100 × 150 × 15 100 x 150 x 15 100 × 150 × 15
Weight (grams) with
bracket
310 300 320
7
