Programming Worksheets
35
Advanced System Programming
Zone Attributes (Section 5.3 “Zone Attributes” on page 16)
Zone Attribute Defaults (Y = Option ON; N = Option OFF):
Section Zone # Zone 1 2 3 4 5 6 7 8
Type*
[101] 1 ( )
I________I I________| I________| I________| I________| I________| I________| I________I
[102] 2 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[103] 3 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[104] 4 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[105] 5 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[106] 6 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[107] 7 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[108] 8 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[109] 9 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[110] 10 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[111] 11 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[112] 12 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[113] 13 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[114] 14 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
[115] 15 ( ) I________I I________| I________| I________| I________| I________| I________| I________I
Attribute: 123456 7 8
ON Audible Steady Chime Bypass Force Swing Tx. Delay Wireless Zn.
OFF Silent Pulsed No No No No No No
Zone Type:
00 Null Zone NNNNNN N N
01 Delay 1 Y Y Y Y N Y N N
02 Delay 2 Y Y Y Y N Y N N
03 Instant Y Y Y Y N Y N N
04 Interior Y Y N Y N Y N N
05 Int. Stay/Away Y Y N Y Y Y N N
06 Dly. Stay/Away Y Y N Y Y Y N N
07 Dly. 24-hr Fire (Hardw.) Y NNNNN N N
08 Stand. 24-hr Fire (Hardw.) Y NNNNN N N
09 24-hr Superv. N Y N N Y N N N
10 24-hr Superv. Buzzer N Y N Y N N N N
11 24-hr Burglary Y Y N Y N N N N
12 24-hr Holdup N Y NNNN N N
13 24-hr Gas Y NNNNN N N
14 24-hr Heating Y NNNNN N N
15 24-hr Medical Y Y NNNN N N
16 24-hr Panic Y Y NNNN N N
17 24-hr Emergency Y Y NNNN N N
18 24-hr Sprinkler Y Y NNNN N N
19 24-hr Water Y Y NNNN N N
20 24-hr Freeze Y Y NNNN N N
21 24-hr Latching Tamper Y Y NNNN N N
22 Momentary Keyswitch NNNNYN N N
23 Maintained Keyswitch NNNNYN N N
24 GSM Answer NNNNYN N N
25 Interior Delay Y Y N Y N Y N N
31 Night Zone YYNYYY N N
87 Dly. 24-hr Fire (Wireless) Y NNNNN N Y
88 Stand. 24-hr Fire (Wireless) Y NNNNN N Y
