DSC PowerSeries PC1832

PowerSeries - PC1616/PC1832/PC1864
Appendix E: Template Programming
Template programming allows quick programming of the minimum functions required for basic operation. The below tables are used to deter-
mine the desired template to be used ( for information on performing template programming see Section 4 – Programming Descriptions). Each
digit represents 1 of the template sections listed below. The option number selected for each digit will make up the 5 digit template programming
code.
• Digit 1 selects Zone 1-8 definition options.
• Digit 2 selects system EOL configuration options.
• Digit 3 selects panel communications options.
Option Zn1 Zn2 Zn3 Zn4 Zn5 Zn6 Zn7 Zn8 1 Delay 1
1 13334444 2 Delay 2
2 13355558 3 Instant
3 13355557 4 Interior
4 11333333 5 Interior Stay/Away
5 13365555 6 Delayed Stay/Away
6 13365558 7 Delayed 24-Hour Fire
Refer to Section 4 for Zone definition details 8 Standard 24-Hour Fire
Option [013] Opt 1 [013] Opt 2
1NC loops ON OFF
2SEOL OFF OFF
3DEOL OFF ON
Op# Phone Line 1 Programming Section Phone Line 2 Programming Section
1 Disabled [380] Opt 1 OFF Disabled [380] Opt 1 OFF
2 SIA automatic Reporting Codes enabled [350] 1st Phone # [04]
[380] Opt 1 ON
[381] Opt 3 OFF
SIA automatic
Reporting Codes
enabled
[350] 2nd Phone # [XX]
3 Contact ID Reporting Codes enabled [350] 1st Phone # [03]
[380] Opt 1 ON
[381] Opt 7 OFF
SIA automatic
Reporting Codes
enabled
[350] 2nd Phone # [XX]
4 SIA automatic Reporting Codes enabled [350] 1st Phone #[04]
[380] Opt 1 ON
[381] Opt 3 OFF
Residential Dial
Enabled
[350] 2nd Phone # [06]
5 Contact ID Reporting Codes enabled [350] 1st Phone # [03]
[380] Opt 1 ON
Opt 7 OFF
Residential Dial
Enabled
[350] 2nd Phone # [06]
6 Contact ID Reporting Codes enabled [350] 1st Phone # [03]
[380] Opt 1 ON
[381] Opt 7 OFF
Contact ID
Reporting Codes
Enabled
[350] 2nd Phone # [03]
