Keypad Quick Guide
The following table summarizes the keys, indicators, and most often used commands of the keypad
.
Status Lights
Ready - Must be on to arm system. All zones must be secured or bypassed and the
system disarmed for this light to activate.
Armed - Indicates system is armed. If the Ready light and the Armed light are both on
it indicates an Exit Delay is in progress.
Trouble - On indicates a system malfunction or tamper. Flashing indicates that the
keypad has a low battery condition. Follow the instructions displayed or enter [,][2] to
view trouble. The Trouble light will turn off when the trouble is corrected.
AC Power - Indicates AC Power is present. The AC Power light will turn off when AC
is absent.
Function Keys
Stay Arms the system in Stay Mode.
Away Arms the system in Away Mode (default).
Chime Same as pressing [,][4] on the keypad.
Reset
Same as pressing
[,][7][2] on the keypad.
Exit Same as pressing [,][0] on the keypad.
Special Keys
Language Selection - Press and hold both buttons simultaneously for 2 seconds to
activate. Scroll to the desired language. Press [,] to select choice.
Fire (F) - Press and hold this button for 2 seconds to activate.
These keys must be
programmed by the
installer to function.
Auxiliary (A) - Press and hold this button for 2 seconds to activate.
Panic (P) - Press and hold this button for 2 seconds to activate.
User Commands
Press [,] to select. Press [<][>] to scroll. Press [#] to exit.
PRESS... To ...
Bypass Zones
Press [0][0] Clear Bypass
Press [9][9] Bypass Recall
Press [9][5] Save Bypass
Press [9][1] Recall Save
View System Troubles Scroll to view all troubles
View Alarms in Memory Scroll to view alarms
Chime ON/OFF Turn chime on and off
