DSC RF5108-433

17
P R O G R A M M I N G W O R K S H E E T S
Partition 7 Wireless Key Options
[67] Function Key 1 03
l
____
l
__ _ _
l
Function Key 3 27
l
____
l
__ _ _
l
Function Key 2 04
l
____
l
__ _ _
l
Function Key 4 30
l
____
l
__ _ _
l
Partition 8 Wireless Key Options
[68] Function Key 1 03
l
____
l
__ _ _
l
Function Key 3 27
l
____
l
__ _ _
l
Function Key 2 04
l
____
l
__ _ _
l
Function Key 4 30
l
____
l
__ _ _
l
[69] Wireless Keys (1-8) Partition Assignments
Default = 01
Wireless Key 01
l
____
l
__ _ _
l
Wireless Key 02
l
____
l
__ _ _
l
Wireless Key 03
l
____
l
__ _ _
l
Wireless Key 04
l
____
l
__ _ _
l
PGM Output Options
Entry Description
00 Null (No Operation)
01 Main Panel PGM1
02 Main Panel PGM2
03 PC5208 PGM3
04 PC5208 PGM4
05 PC5208 PGM5
06 PC5208 PGM6
07 PC5208 PGM7
08 PC5208 PGM8
Wireless Key 05
l
____
l
__ _ _
l
Wireless Key 06
l
____
l
__ _ _
l
Wireless Key 07
l
____
l
__ _ _
l
Wireless Key 08
l
____
l
__ _ _
l
Entry Description
09 PC5208 PGM9
10 PC5208 PGM10
11 PC5204 PGM11
12 PC5204 PGM12
13 PC5204 PGM13
14 PC5204 PGM14
15 RF5108 PGM Pulse (local)
16 RF5108 PGM Toggle (local)
[70] RF5108 PGM1 Output Option
Default = 01
PGM1 Output Option
l
________
l
________
l
[71] RF5108 PGM2 Output Option
Default = 02
PGM2 Output Option
l
________
l
________
l
[72] RF5108 - PGM1 Output Activation Time
Default = 00
PGM1 Output Activation Time (Minutes)
l
________
l
________
l
Default = 05
PGM1 Output Activation Time (Seconds)
l
________
l
________
l
[73] RF5108 - PGM2 Output Activation Time
Default = 00
PGM2 Output Activation Time (Minutes)
l
________
l
________
l
Default = 05
PGM2 Output Activation Time (Seconds)
l
________
l
________
l
NOTE: Sections [72] and [73] have a valid minimum programmable value of 00 minutes 01
seconds, and a valid maximum programmable value of 99 minutes 99 seconds.
