2
1.2 Specifications and Features
• Voltage: 12VDC
• Current Draw: 40mA
• Frequency: 433.92 MHz
• Zones - receiver can receive signals from up to 8 wireless zones and 8 wireless keys
• Internal antenna
• PGM Outputs: 2 Open-collector PGM outputs (50mA)
• Supervisory - programmable supervisory window, 4 - 24 hours, in 15 minute
increments
• Location
- can be wired up to 750 ft. / 230 m from the main panel with 22 gauge wire; the wiring
used in this circuit connection must be insulated with PVC, TFE, PTFE, FEP, Neoprene
or Polymide
- connects to Keybus
- for longer wire runs, thicker gauge wire must be used.
• Compatibility: The RF5108-433 v1.x can be connected to the following panels:
PC5020,
PC501X, PC1555, PC1565, PC580, PC585
1.3 Compatible Wireless Devices
Please refer to the Instruction sheets of the following devices for more information.
The RF5108-433 v1.0 can receive signals from the following devices:
• WLS904L-433 Motion Detector • WLS912L-433 Glass Break Detector
• WLS904PL-433 Pet Immune PIR • WLS914 Pet Immune PIR
• WLS906-433 Smoke Detector • WLS919-433 Wireless Key
• WLS907T-433 Low Temperature Sensor • WLS925L-433 Mini Door/Window Contact
• WS4939 Wireless Key
1.4 DLS Compatibility
The RF5108-433 can support up to 8 wireless devices that can be assigned to any of zones
1 to 32 or RF Jam Zone. If the DLS user enters valid serial numbers for more than 8 wireless
devices and the wireless device serial numbers are downloaded, the RF5108-433 will
accept the serial numbers of the first 8 wireless devices (in order, starting with the lowest
zone number).
1.5 Batteries
The wireless devices are designed to use only specific brands and types of batteries.
Please see the appropriate instruction sheet for detailed information on the battery
brands and types.
NOTE: Do not use brands of batteries other than those specified. Using any other brand
may affect system operation.
Section 2: RF5108-433 Set Up & Wiring
This section describes how to set up and wire the RF5108-433 module.
2.1 Unpack the RF5108-433
Check that the following parts are in your RF5108-433 package:
• 1 WS4939 wireless key (WKK-1) or 2 with WKK-2
• RF5108-433 in cabinet
• Hardware for mounting the cabinet
• LED indicator plate
I N T R O D U C T I O N
