3.4 Identified Wireless Keys
Reporting by the system of openings/closings by individual wireless keys and command
output [✱][7] activation by wireless key buttons may be supported on certain control panels.
To do this, the system will reserve access codes 17-24 for wireless keys 01-08 respectively.
You must program one access code for each wireless key (using [✱][5] access code
programming) for this feature to work correctly.
NOTE: Program these access codes on the system after you have connected the RF5108-
433 to the Keybus (see section 2.4).
Refer to your system
Installation Manual
for information on access code programming.
Opening/Closing By Wireless Key Reporting
NOTE: The Identified Wireless Key Closing option is only available with the PC5020,
PC501X, PC1555, PC1565, PC580, PC585 v2.0 and higher by turning section [015]
option 4 off.
To enable the reporting of openings and closings
by identified wireless keys:
• Make sure the control panel is v2.0 or higher
• Program a valid access code for each key
• Program a closing and opening reporting code for each key’s access code
• Turn off the Quick Arm option in section [015] option [4] of the control panel programming
To ensure that an
unidentified wireless key
cannot disarm the system, turn off section [017],
option [1] (in the control panel programming). This option is available in control panels with
software version 2.1 or higher.
Command Output Activation
NOTE: The Identified Wireless Key Command Output Activation feature is only available
with the PC5020, PC501X, PC1555, PC1565, PC580, PC585 v2.0 and higher.
To enable command output activation by wireless keys, ensure that:
• The control panel is v2.0 or higher
• Program a valid access code for each key
• Enable the PGM output attribute Requires Access Code for each PGM output
programmed as [✱][7][1-4] in sections [141] to [154].
3.5 RF5108-433 PGM Outputs
The RF5108-433 has two on-board open collector PGM outputs. Each of these can be
individually programmed to:
1. Follow main panel PGM outputs 1 to 14.
NOTE: Please refer to your System Installation Manual for available PGM outputs.
NOTE: If the RF5108-433 is connected to the PC580/PC585/PC1555/PC1565/P-48/
P-6B, PC5010 v1.x, P832 v1.x or the WSS5010 1.0, 2.1, the RF5108-433 PGM out-
puts cannot be programmed to follow main panel PGM outputs 1 or 2. The PC1555MX
will have this functionality.
2. Activate for a programmable amount of time when a signal is received from a
wireless key programmed with output option 31 or 32 (RF5108-433 PGM pulse) and
the PGM output programming section [70] or [71] is programmed with option 15
(RF5108-433 PGM pulse). The amount of time that the PGM outputs can be
programmed to remain on is programmed in sections [72] and [73]. The default
activation time is 5 seconds.
3. Toggle state when a signal is received from a wireless key programmed with
option 31 or 32 and the PGM output programming section [70] or [71] is
programmed with option 16 (RF5108-433 PGM toggle).
