9
To review which modules the control panel is currently supervising:
1. Enter [✱][8][Installer’s Code]
2. Enter [903] to display all modules. On LED keypads, light [17] will indicate that
the RF5108-433 is present on the system. On LCD keypads, scroll until the
module name ‘PC5132’ appears on the display.
3. To exit press [#].
If the RF5108-433 module does not show on the keypad, one of the following conditions
may be present:
• the module is not connected properly to the Keybus
• there is a problem with the Keybus wiring run
• the module does not have enough power
• no devices have been enrolled on the RF5108-433
4.3 Enable Supervision of Wireless Zones
NOTE: (for PC5010 v1.x control panels only)
For UL Listed installation, Double EOL
resistors must be enabled in the PC5010 for the wireless zones to be supervised. If nor-
mally Closed or Single EOL resistors are selected the PC5010 will not be able to supervise
the wireless devices. If a wireless device stops sending a supervisory signal (the unit stops
functioning) the panel will not indicate a supervisory trouble condition unless Double EOL
resistors are used. In addition, all hardwire zones must be wired for Double EOL resistors.
For more information, refer to your PC5010 v1.x Installation Manual.
NOTE:
(PC5010 v2.0 and higher, PC5015 v2.2 and higher, PC5020, PC5008, PC1555,
PC1565, PC580, PC585 only): For wireless supervision to work, you must enable the
wireless zone attribute on all wireless zones (sections [101] to [132], option [8] ON).
Wireless Supervisory Window
Each wireless zone will send a supervisory signal at a fixed time interval (64 minutes for
NA, 12 minutes for EU). If the receiver does not receive a signal within the time
programmed for the Wireless Supervisory Window, it will generate a supervisory fault.
To program the wireless supervisory window:
1. Enter [✱][8][Installer’s Code] to enter Installer Programming.
2. Enter [804] to enter the RF5108-433 Module Programming.
3. Enter section [81].
4. Enter the time period for the supervisory window. The window is programmed in 15
minute increments.
• The default programming for NA is 96 (x15 minutes), which is equal to 24 hours.
Valid entries for NA are (16) - (96), equal to 4 - 24 hours.
• The default programming for EU is 10 (x15 minutes), which is equal to 2.5 hours. Valid
Entries for EU are (08) - (96), equal to 2 - 24 hours.
5. To exit press [#].
Disable/Enable Zone Supervision
All wireless zones have supervision enabled by default. To disable supervision for any
zone, enter the following at any system keypad:
1. Enter [✱][8][Installer’s Code] to enter Installer Programming.
2. Enter [804] to enter the RF5108-433 Module Programming.
3. Enter section [82]-[85]. Enable or disable supervision for each wireless zone by
turning each relevant option on or off.
4. To exit press [#].
NOTE:
The RF Jam Detect zone must have the supervision option disabled.
O T H E R P R O G R A M M I N G
