Please refer to the control panel Installation Manual for a listing of available output types
and their function. PGM 1 and/or PGM 2 on the RF5108-433 can be set up for this
operation (see Section 3.5).
After you have completed the wiring, reconnect the power to the security system.
Now that you have wired the RF5108-433, you should enroll and program the wireless
devices. See section 3 for instructions.
Section 3: Enrolling Wireless Devices
This section describes how to enroll wireless devices and wireless keys. For more
information on these devices, read the instruction sheet included with each device.
3.1 A Note about Electronic Serial Numbers
An electronic serial number (ESN) is printed on the back of each wireless device. ESNs
are used to enroll the wireless devices with the RF5108-433 receiver.
In order to reduce the occurrence of wireless devices with the same serial number, 6-
digit serial numbers are printed on the back of each wireless device. The 6-digit serial
numbers include hexadecimal digits. For instructions on programming hexadecimal
numbers, see your system
Installation Manual
, section 4: ‘How to Program’.
NOTE: 6-digit serial numbers are only supported on the following control panels: PC5020,
PC501X, PC1555, PC1565 and PC580, PC585 v2.0 and higher.
The WLS904L/904PL-433, WLS906-433, WLS907T-433, WLS912L-433, WLS914-433,
and WLS925L-433 devices have a 6-digit serial number printed on them. When
connecting the RF5108-433 to a PC5015 v2.x and higher, PC5020, PC5010, PC1555/
1565, or PC580/585 panel enter the 6-digit serial number.
3.2 Enrolling Wireless Devices
1. At a system keypad, enter [✱][8][Installer’s Code] to go to the Installer
Programming section.
2. Enter programming section [804].
3. Enter the 2-digit number corresponding to the zone the device is to occupy ([01]
to [32]).
NOTE: Hardwired and wireless devices cannot be assigned to the same zone.
PowerSeries panels v2.x and lower that support the PC5108 zone expander modules
occupy zones in 2 groups of 4 (e.g. zones 9-12 and zones 13-16). PowerSeries panels
v3.x and higher that support the PC5108 zone expander modules occupy zones in
groups of 8 (e.g. zone 9-16 and 17-24). None of the zones assigned to a PC5108 module
may be used for wireless devices. For more information on zone assignment, refer to
your System Installation Manual.
4. Enter the device’s ESN. Follow the instructions in section 3.1 above.
5. Record the serial number and the assigned zone number in the programming
worksheets in the back of this manual.
6. Repeat steps 3 - 5 until you have enrolled up to 8 wireless devices.
NOTE: The RF5108-433 supports programming of 8 wireless devices that can be as-
signed to any of zones 1 to 32 or RF Jam Zone. Once 8 wireless devices have been
programmed the RF5108-433 will not allow further programming. An error tone will be
heard at the keypad if further programming is attempted.
7. To exit press [#]. The device is now enrolled on the system.
NOTE: The devices will not work properly until you complete zone and partition program-
ming (see section 4).
S E T U P & W I R I N G
To Next Page
