DSC RF5108-433 - Jamming Detection Configuration; RF Jamming Detection Setup

19
ON
l
________
l
Option 3 Zone 19 Supervision enabled Disabled
ON
l
________
l
Option 4 Zone 20 Supervision enabled Disabled
ON
l
________
l
Option 5 Zone 21 Supervision enabled Disabled
ON
l
________
l
Option 6 Zone 22 Supervision enabled Disabled
ON
l
________
l
Option 7 Zone 23 Supervision enabled Disabled
ON
l
________
l
Option 8 Zone 24 Supervision enabled Disabled
[85] Zone Device Supervision Options (25-32)
Default Option ON Option OFF
ON
l
________
l
Option 1 Zone 25 Supervision enabled Disabled
ON
l
________
l
Option 2 Zone 26 Supervision enabled Disabled
ON
l
________
l
Option 3 Zone 27 Supervision enabled Disabled
ON
l
________
l
Option 4 Zone 28 Supervision enabled Disabled
ON
l
________
l
Option 5 Zone 29 Supervision enabled Disabled
ON
l
________
l
Option 6 Zone 30 Supervision enabled Disabled
ON
l
________
l
Option 7 Zone 31 Supervision enabled Disabled
ON
l
________
l
Option 8 Zone 32 Supervision enabled Disabled
[90] Other Options
Default Option ON Option OFF
OFF
l
________
l
Option 1-6 For Future Use
NA=ON
l
________
l
Option 7* RF Jam Detect Disabled Enabled
EU=OFF
OFF
l
________
l
Option 8 Global Placement Test Individual Placement Test
RF Jamming Detection
[93] RF Jam Detect Zone
Default = 00*
l
____
l
__ _ _
l
Select an unused zone that will be set to the tamper state when a jamming
signal is detected. (Valid entries = 01 - 32, 00 = No RF Jam zone selected)
NOTE: *For UL Listed installations the RF Jam detection zone must be enabled.
Use a non hardwired zone (9-32) for UL when selecting an RF jamming zone.
Ensure the zone type selected is 03 (Instant) when programmed in the control
panel portion.
