2. The HSPA3GCellular path isimmune to conducted and radiated RF fields
with levelsup to 10V/mastested per EN50130-4 Standard.
3. The TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)Emodule conforms
with radiated emissionslevelsforClassBequipment asperstandards
EN61000-6-3/EN55022/CISPR22.
4. The TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)Emodule uses
AES128 encryption and heartbeat supervision forHSPA3GCellularcom-
munication pathsand it meetssecuritylevelsS2 asperEN50136-2:2013.
It also usesauthentication foreachmessage exchanged with the com-
patiblereceiverequipment at ARC and it meetslevelI2 forinformation
security.
5. The 3G2080(R)E-EUmodule hasonlyone communication path:
HSPA3GCellularcommunication path using 900/1800/2100MHzPublic
CellularNetwork.The HSPA3G Cellularcommunication path that can be
used in a standalone mode inconjunction with a DSC alarmsystem(com-
patibleDSCalarmcontrolpanelmodels: HS2128/064/032/016).The sup-
ported ATSconfiguration is: customcategoryC.
6. The TL280(R)Emodule hasonlyone communication path: Ethernet com-
munication path using Internet. The communication path that can be used
in a standalone mode inconjunction with a DSC alarmsystem(compatible
DSC alarmcontrolpanelmodels: HS2128/064/032/016).The supported
ATSconfiguration is: customcategoryC.
7. The TL2803G(R)E-EUmodule hastwo communication paths: HSPA3G
Cellularcommunication path using 900/1800/2100MHzPublicCellularNet-
workand Ethernetcommunication path using Internet. The com-
munication pathscan be used in a standalone mode inconjunction with a
DSC alarmsystem(compatibleDSCalarmcontrolpanelmodels:
HS2128/064/032/016). The supported ATSconfiguration is: customcat-
egoryC.
8. TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)Ehasbeen tested forcom-
pliancein conjunction with the following applicable standards:EN50136-
1:2012, EN50136-2:2013, EN50131-10:2014, ATSconfiguration: C.
ForEN50131-1:2006/A1:2009 compliant installations,the following programming
optionsshallbe set asdescribed.
Supervision Heartbeat: shallbe set to 180 seconds
NOTE:The compatiblereceiverat ARC location shallhave supervision window pro-
grammed for 180 seconds. TL2803G(R)E-EU/3G2080 (R)E-EU/TL280(R)E has
been certified by TELEFICATION in accordance with EN50131-1:2006/A1:2009,
EN50131-10:2014 requirementsfor Grade 2, ClassIIand EN50136-2:2013 Con-
figuration: C
ATS Custom Category C Level
EN50136-1:2012 AnnexD Table D.1 D3
EN50136-1:2012 AnnexD Table D.2 M3
EN50136-1:2012 AnnexD Table D.3 T4
EN50136-1:2012 AnnexD Table D.4 A4 (Depending on cellularcarrierused)
EN50136-1:2012 AnnexD Table D.5
S2 (use AES- 128 and
authentication/sequentialinformation in
each message transmitted to the SG
receiver)
EN50136-1:2012 AnnexD Table D.6 I2 (useAES-128 encryption)
EN50136-1:2012 Table 1
Use single communication path for
models 3G2080 (R) E- EU (cellular
network), TL280 (R) E (Ethernet port)
and two communication pathsfor model
TL2803G(R)E-EU (cell/Ethernet).
EN50136-1:2012 Table 4 ATSfailure reported to ARC
EN50136-1:2012 Table 5
ATS failure reported to AS (DSC
compatible control panel
HS2128/HS2064/HS2032/HS2016)
EN50136-1:2012 Table 6
There is no recording of availability
failure
EN50136-2:2013 Table 1 No logging function provided
EN50136-2:2013 Table 2
No memory provided for logging
function
EN50136-2:2013 Table 3 ATSfailure reported to ARC
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby, TycoSafetyProductsCanada Ltd declaresthat the radio equipment type
isin compliance with Directive 2014/53/EU. The full text of the EU declarations of
conformityfor the models mentioned below are available at the following internet
addresses:
TL2803G(R)E-EU -http://dsc.com/pdf/1605003
3G2080(R)E-EU-http://dsc.com/pdf/1605004
Frequency Band Maximum Power
EGSM900 890.0MHz-914.8MHz Class4 (2W)@ 900MHz,GSM
EGSM900 880.2MHz-889.8MHz Class1(1W)@ 1800MHz,GSM
DCS1800 1710.2MHz-1784.8MHz ClassE2 (0.5W)@ 900MHz,EDGE
WCDMA (Band VIII) 882.4MHz -
912.6MHz
ClassE2 (0.4W)@ 1800MHz,EDGE
WCDMA2100 (Band I) 1922.4MHz -
1977.6MHz
Class 3 (0.25W) @ 900/2100MHz,
WCDMA
Onlymodels TL2803GRE-EU, TL2803GE-EU, 3G2080RE-EU, 3G2080E-EU are
CEcompliant.
European single point of contact: Tyco Safety Products, Voltaweg 20, 6101 XK
Echt, Netherlands
UL/ULC Installation Requirements
NOTE:Forequipment used at the protected premises and intended to facilitate IP
communications (hubs, routers, NIDs, Digital Subscriber Line (DSL), cable
modems),24 hourbackup poweris required. Where suchcannot be facilitated, a
secondary(back-up)communication channelisrequired.
Domain Name Service (DNS) programming is not permitted in UL1610
listed systems.
Technical Specifications
The input voltage to the Communicatorcan be drawn from the Underwriters Lab-
oratories/UnderwritersLaboratoriesCanada (UL/ULC)listed controlpanel.
Notes for using Private, Corporate, and High Speed Data Networks:
Networkaccessand domainaccesspoliciesshallbe set to restrictunauthorized net-
workaccess, and spoofing or Denial of Service (DoS) attacks. Select an Internet
Service Provider(ISP)that hasredundant servers/systems, back-up power, routers
with firewalls enabled, and methods to identify and protect against DoS attacks
(e.g., via spoofing).
Notes for using Public Switched and Cellular Data Networks:
Communication channelsshallbe facilitated such that the communicatorwill restrict
unauthorized access, which could otherwise compromise security. The com-
municatorshallbe located in a secured area.
• For ULC Residential Fire and Burglary applications the TL2803G (R)
E/3G2080(R)E/TL280(R)E/LE2080(R)/TL280LE(R)can be used asprimary com-
munication channelvia eithercellularorEthernet orasa back-up in conjunction with
the Digital Alarm Communicator Transmitter (DACT). Test transmission every 24
hoursshallbe enabled on each channel.
• For ULC Commercial Fire and Burglary applications the TL2803G (R)
E/3G2080(R)E/TL280(R)E/LE2080 (R)/TL280LE(R) can be used as a passive
communication module with the following securitylevels:
l P1 (each channelcellular orEthernet isindependent)
l P2 (cellular and Ethernet in back-up configuration, panelsection [851][005]
toggle option [5] OFF).
l P3 (cellular and Ethernet in redundantconfiguration, panelsection [851]
[005]toggle option [5] ON).
The communicator can also be used as an activecommunication system with the
securitylevelsA1-A4 (each channelcellular orEthernet independent ortogether in
a back-up/redundant configuration). For active line security systems AES128 bit
encryption shallbe enabled (at the monitoring station receiver)and the supervision
heartbeatrate shallbe set as90 seconds (panelsection [851][004] = 005A/90).
The supervision window at the SignalReceiverCenter(SRC)'sreceiver shallbe pro-
grammed asmaximumof 180 (00B4/180)seconds.
NOTE: For ULC commercial fire passive communication, encryption shall be
enabled,
• For UL Residential Fire and Burglary applications the TL2803G (R)
E/3G2080R/TL280(R)E/LE2080(R)/TL280LE(R)can be used asthe primarycom-
munication channel via either cellular or Ethernet, or asa back-up in conjunction
with the DACT(30 daytest transmission isrequired on each channel).
• For UL Commercial Burglary applications the TL2803G(R)E/ 3G2080R /
TL280(R)E / LE2080(R) / TL280LE(R) can be used asdual signalling line com-
munication system (cellular and Ethernet channels used in redundant con-
figuration),standard line securityand asencrypted line security.
• The supervision heartbeat shall be enabled (panel section [851][005] toggle
option [1] (Ethernet)and/or toggleoption [2] (cellular) shallbe ON),toggle option
[3] (supervision type)shallbe ON and the supervision heartbeat rate shallbe selec-
ted as135 (0087/135)seconds.Option [004] = 0087. The supervision window at
the supervising station shall be maximum200 (00C8/200)seconds.For encrypted
line security systemsthe encryption AES128 bit shall be enabled at the monitoring
station receiver.
• For UL Commercial Burglary installations, the TL2803G (R)E/3G2080 (R)
E/TL280(R)E/LE2080 (R)/TL280LE(R) is listed asa primary (sole) communication
means(heartbeat must be enabled) or for supplementary (back-up) use in con-
junction with a Plain Old Telephone Service (POTS)line dialer.When the heartbeat
transmission over the Ethernet orcellular networkis enabled, using the TL2803G
(R)E/3G2080 (R)E/TL280 (R)E with a compatible control unit listed for stand-
ard/encrypted line security,it can provide line securityforthe alarmsystemover the
primaryline.
•The TL2803G(R)E/3G2080(R)E/TL280(R)E/LE2080(R)/TL280LE(R)isalso suit-
able to be used with a compatible control unit listed for dual line security trans-
mission when used in conjunction with a DACT ora Public Switched Data Network
(PSDN)transmitter, where the PSDN provides the line security and is the primary
line. In this mode, alarmsignals are required to be sent simultaneously over both
communication methods.
19
