DSC WP8033 User Manual

20 D-306048 WP8033 Installer's Guide
APPENDIX A. Specifications
A1. Functional
Zones Number
Up to 64 wireless zones, (including 2 hard-wired inputs).
Hard-wired Zone Requirements
2.2 kE.O.L. resistance (max. resistance of wires 220 
Maximum Loop Current
1.5 mA
Maximum Loop Voltage
3.3 V
Loop Shorted
0 – 1.47 V (0 – 1.770 Ω)
Loop Normal
1.47 – 1.8 V and 2.02 – 2.3 V
Loop Open
2.3 – 3.3 V (5.06 - ∞ Ω)
Installer and User Codes
 1 master installer (9999 by default)*
 1 installer (8888 by default)*
 1 master user, no. 1 (1111 by default)
 Users nos. 2 - 48
* Codes must not be identical
Control Facilities
- Integral keypad, wireless keyfobs and keypads
- SMS commands via optional GSM/GPRS module.
- Remote control by telephone.
Arming Modes
AWAY, HOME, AWAY-INSTANT, HOME-INSTANT, LATCHKEY, FORCED, BYPASS.
Alarm Types
Silent, personal panic/emergency, burglary, gas, fire and flood.
Siren Signals
Continuous (intrusion / 24 hours / panic); triple pulse – short pause - triple pulse... (fire);
four pulses – long pause – four pulses... (gas);
long pulse – long pause – long pulse... (flood).
Siren (bell) Timeout
Programmable (4 min. by default)
Internal Sounder Output
At least 85 dBA at 3 m (10 ft)
Supervision
Programmable time frame for inactivity alert
Special Functions
- Chime zones
- Diagnostic test and event log.
- Local and Remote Programming over Telephone, GSM /GPRS connections.
- Calling for help by using an emergency transmitter.
- Tracking inactivity of elderly, physically handicapped and infirm people.
- Message center (recording and playback)
Data Retrieval
Alarm memory, trouble, event log
Real Time Clock (RTC)
The control panel keeps and displays time and date. This feature is also used for the log
file by providing the date and time of each event
Battery Test
Once every 10 seconds
A2. Wireless
RF Network
PowerG – 2-way synchronized Frequency Hopping (TDMA / FHSS)
Frequency bands (MHz)
433 – 434
868 - 869
912 - 919
Hopping frequencies
8
4
50
Region
Worldwide
Europe and South Africa
North America and
selected countries
Encryption
AES-128
A3. Electrical
External AC/AC adaptor
NA
External AC/DC adaptor
External (wall-mounted) switching power supply 100VAC to 240VAC, 50/60 Hz, 0.5A
/ 12.5 VDC, 1.2A
Internal AC/DC
Internal switching power supply:
Input: 100-240VAC, 0.75A
Output: 12.5 VDC, 1.6A.
Current Drain
Approx. 260 mA standby at the beginning (power ON) and then goes down to 60 mA,
1400 mA max. current drain during alarm.
Low Battery Threshold
7.2 V (6-cell battery pack)
9.6 V (8-cell battery pack)
Backup Battery Pack
Backup Battery Options:
Backup period
Maximum external devices current (1)
1300 mAh
6 Battery Pack (2)
1800 mAh
8-BatteryPack (3)
2200 mAh 8-Battery
Pack (4)
4h
180 mA
300 mA
380 mA
8h
70 mA
125 mA
160 mA
12h
35 mA
70 mA
95 mA
24h
max backup w/o
load 22 hours
12 mA
25 mA
32h
no backup
0 mA
10 mA
39h
no backup
no backup
0 mA
