Installation

057-254 ISSUE: 2 Page 78 of 188

3.5.3 MULTI GENERATORS WITH SINGLE SYNCHRONISING TRANSFER SWITCH

NOTE: The below diagram is available in a larger scale. Contact DSE technical support for further information, support@deepseaplc.com.

Questions and Answers:

Need help?

Do you have a question about the DSE 8610 MKII and is the answer not in the manual?

DSE 8610 MKII Specifications

General

Generator & Mains Frequency	3.5 Hz to 75 Hz
Display	LCD with backlight
Communication	RS232, RS485, Ethernet, USB
Inputs	4 analogue inputs
Outputs	Configurable x 8
Power Supply	8 to 35 V DC
Operating Temperature	+70°C
Dimensions	240mm x 181mm x 42mm
Magnetic Pick-up Voltage Range	0.5 V
Magnetic Pick-up Frequency	10, 000 Hz (max)
Protection Rating	IP65 (Front only)
