DSE2157
DSENET
®
OUTPUT EXPANSION MODULE
DSEGenset
®
The DSE2157 is an output relay
expansion module for use with
DSENet
®
compatible control
modules. The DSE2157 has been
designed to extend a host module’s
output capabilities.
A maximum of 10 DSE2157’s can be
connected to an individual module at
any one time. All outputs
are configurable via the host
controller.
The additional output capabilities of
the DSE2157 give OEMs the
flexibility to meet increasingly
complex industry specifications.
The module incorporates ‘DIN’ rail
and chassis mountings allowing
convenient fixing into a panel.
The module will work up to 1 KM
(0.6miles) from the host control
module.
ENVIRONMENTAL TESTING STANDARDS
ELECTRO-MAGNETIC COMPATIBILITY
BS EN 61000-6-2
EMC Generic Immunity Standard for
the Industrial Environment
B
S EN 61000-6-4
EMC Generic Emission Standard for
the Industrial Environment
ELECTRICAL SAFETY
B
S EN 60950
Safety of Information Technology Equipment,
including Electrical Business Equipment
TEMPERATURE
BS EN 60068-2-1
Ab/Ae Cold Test -30
o
C
B
S EN 60068-2-2
Bb/Be Dry Heat +70
o
C
VIBRATION
BS EN 60068-2-6
Ten sweeps in each of three
major axes
5 Hz to 8 Hz @ +/-7.5 mm,
8 Hz to 500 Hz @ 2 gn
HUMIDITY
BS EN 60068-2-30
Db Damp Heat Cyclic 20/55
o
C
@
95% RH 48 Hours
B
S EN 60068-2-78
Cab Damp Heat Static 40
o
C
@
93% RH 48 Hours
S
HOCK
B
S EN 60068-2-27
Three shocks in each of three major axes
15 gn in 11 mS
HOST MODULE (1)
1
DSENET
®
EXPANSION
DC POWER
SUPPLY 8-35V
COMPREHENSIVE FEATURE LIST TO SUIT A WIDE VARIETY
OF GEN-SET APPLICATIONS
7
OTHER
DSE2157
VOLT-FREE NORMALLY OPEN OUTPUTS VOLT-FREE CHANGE OVER OUTPUTS
DSENET
®
2
1
5
7
2
1
3
0
2
5
1
0
/
2
0
2
5
4
8
4 4
COMPATIBLE WITH DSE7310/20, DSE8610/60/80 & DSE8710/60
HOST MODULE
ISSUE 3
