DTS JACK - DMX Protocol - 25 Channels Mode; DMX Channel 17: FIXED GOBO SHAKE; DMX Channel 18: IRIS; DMX Channel 19: MACROS

31
DMX CHANNEL
17
Parameter: FIXED GOBO SHAKE
DMX value
Function
000-009
Stop
010-022
Gobo shake R-L speed 1
023-035
Gobo shake R-L speed 2
036-048
Gobo shake R-L speed 3
049-061
Gobo shake R-L speed 4
062-074
Gobo shake R-L speed 5
075-087
Gobo shake R-L speed 6
088-100
Gobo shake R-L speed 7
101-113
Gobo shake R-L speed 8
114-126
Gobo shake R-L speed 9
127-138
Stop
139-151
Gobo shake L-R speed 1
152-164
Gobo shake L-R speed 2
165-177
Gobo shake L-R speed 3
178-190
Gobo shake L-R speed 4
191-203
Gobo shake L-R speed 5
204-216
Gobo shake L-R speed 6
217-229
Gobo shake L-R speed 7
230-242
Gobo shake L-R speed 8
243-255
Gobo shake L-R speed 9
DMX CHANNEL
18
Parameter: IRIS
DMX value
Function
000-009
Open
010-246
Linear iris from open to closed
247-255
Closed
DMX CHANNEL
19
Parameter: MACROS
IF CHANNEL 20 = IRIS MACROS (DMX range value 0-63)
DMX value
Function
000-009
No effect
010-063
Iris pulse at different speed from min to max
064-117
Iris pulse with flash closing from min to max
118-171
Iris pulse with flash opening from min to max
172-213
Iris pulse with flash closing combined with zoom from min to max
214-255
Iris pulse with flash opening combined with zoom from min to max
IF CHANNEL 20 = BEAM MACROS (DMX range value 64-127) BEAM Macros not yet implemented
DMX value
Function
000-009
No effect
010-063
BEAM macros 1
064-117
BEAM macros 2
118-171
BEAM macros 3
172-213
BEAM macros 4
214-255
BEAM macros 5
IF CHANNEL 20 = WASH MACROS (DMX range value 128-191) WASH Macros not yet implemented
DMX value
Function
000-009
No effect
010-063
WASH macros 1
064-117
WASH macros 2
118-171
WASH macros 3
172-213
WASH macros 4
214-255
WASH macros 5
