DTS JACK User Manual

32
IF CHANNEL 20 = SPOT MACROS (DMX range value 192-255) SPOT Macros not yet implemented
DMX value
Function
000-009
No effect
010-063
SPOT macros 1
064-117
SPOT macros 2
118-171
SPOT macros 3
172-213
SPOT macros 4
214-255
SPOT macros 5
DMX CHANNEL
20
Parameter: MACROS MODE
DMX value
Function
000-063
IRIS macros
064-127
BEAM macros (BEAM Macros not yet implemented)
128-191
WASH macros (WASH Macros not yet implemented)
192-255
SPOT macros (SPOT Macros not yet implemented)
DMX CHANNEL
21
Parameter: PRISM
DMX value
Function
000-127
No Effect
128-255
Prism Inserted
DMX CHANNEL
22
Parameter: FOCUS
DMX value
Function
000-255
Linear focus (0-95)%
DMX CHANNEL
23
Parameter: FOCUS FINE
DMX value
Function
000-255
Linear focus (95-100)%
DMX CHANNEL
24
Parameter: ZOOM
DMX value
Function
000-255
Linear zoom
DMX CHANNEL
25
Parameter: RESET + LAMP
DMX value
Function
000-009
No effect
010-060
Lamp OFF (3 sec)
061-129
No effect
130-179
Lamp ON (3 sec)
180-200
No effect
201-239
Internal motor reset
240-255
Total reset
