DTS JACK User Manual

33
22- DMX PROTOCOL
17 CHANNELS MODE
1 PAN msb
2 PAN lsb
3 TILT msb
4 TILT lsb
5 SPEED MOVEMENT
6 PAN FAR (Active only on Jack FPR Cod. 03.MS012.EBLFP)
7 DIMMER
8 SHUTTER
9 COLOUR
10 GOBO
11 GOBO ROTATION / INDEX – PRISM ROTATION
12 FIXED GOBO
13 IRIS
14 PRISM
15 FOCUS
16 ZOOM
17 RESET + LAMP
DMX CHANNEL
1
Parameter: PAN msb
DMX CHANNEL
2
Parameter: PAN lsb
DMX CHANNEL
3
Parameter: TILT msb
DMX CHANNEL
4
Parameter: TILT lsb
DMX CHANNEL
5
Parameter: SPEED MOVEMENT
DMX value
Function
000-010
Standard
011-025
Fast movement
026-127
Vector mode from fast to slow
128-247
Variable time reaction to DMX signal (fast to slow)
248-255
Silent movement
