DTS JACK User Manual

36
DMX CHANNEL
10
Parameter: GOBO
DMX value
Function
000-020
Open
021-041
Gobo 1
042-062
Gobo 2
063-083
Gobo 3
084-104
Gobo 4
105-125
Gobo 5
126-146
Gobo 6
147-167
Gobo 7
168-188
Gobo 8
189-207
Gobo 9
208-213
Speed rotation 1 min
214-219
Speed rotation 2
220-225
Speed rotation 3
226-231
Speed rotation 4
232-237
Speed rotation 5
238-243
Speed rotation 6
244-249
Speed rotation 7
250-255
Speed rotation 8 max
DMX CHANNEL
11
Parameter: GOBO ROTATION / INDEX – PRISM ROTATION
DMX value
Function
000-127
Proportional index 0°-360°
128-180
Left rotation (max to min)
181-202
Stop
203-255
Right rotation (min to max)
DMX CHANNEL
12
Parameter: FIXED GOBO
DMX value
Function
000-018
Open
019-037
Gobo 1
038-056
Gobo 2
057-075
Gobo 3
076-094
Gobo 4
095-113
Gobo 5
114-132
Gobo 6
133-151
Gobo 7
152-170
Gobo 8
171-189
Gobo 9
190-207
Gobo 10
208-213
Speed rotation 1 min
214-219
Speed rotation 2
220-225
Speed rotation 3
226-231
Speed rotation 4
232-237
Speed rotation 5
238-243
Speed rotation 6
244-255
Speed rotation 7 max
