DTS JACK User Manual

37
DMX CHANNEL
13
Parameter: IRIS
DMX value
Function
000-009
Open
010-124
Linear Iris from open to closed
125-132
Closed
133-159
Iris pulse at different speed from min to max
160-186
Iris pulse with flash closing from min to max
187-213
Iris pulse with flash opening from min to max
214-234
Iris pulse with flash closing combined with zoom from min to max
235-255
Iris pulse with flash opening combined with zoom from min to max
DMX CHANNEL
14
Parameter: PRISM
DMX value
Function
000-127
No effect
128-255
Prism inserted
DMX CHANNEL
15
Parameter: FOCUS
DMX value
Function
000-255
Linear focus
DMX CHANNEL
16
Parameter: ZOOM
DMX value
Function
000-255
Linear zoom
DMX CHANNEL
17
Parameter: RESET + LAMP
DMX value
Function
000-009
No effect
010-060
Lamp OFF (3 sec)
061-129
No effect
130-179
Lamp ON (3 sec)
180-200
No effect
201-239
Internal motor reset
240-255
Total reset
